When to replace the Spark Plug on your TOYOTA YARIS
Recommended replacement interval for the part category Spark plug : 4 year / 60000 km
Important!
This replacement procedure can be used for:
TOYOTA AURIS (NRE15_, ZZE15_, ADE15_, ZRE15_, NDE15_) 1.4 (ZZE150_), TOYOTA Yaris Hatchback (_P9_) 1.3 VVT-i (NCP90_), TOYOTA Yaris Hatchback (_P9_) 1.5 (NCP91_), TOYOTA COROLLA (ZZE12_, NDE12_, ZDE12_) 1.8 VVTi (ZZE122_), TOYOTA COROLLA (ZZE12_, NDE12_, ZDE12_) 1.6 VVT-i (ZZE121_), TOYOTA COROLLA (ZZE12_, NDE12_, ZDE12_) 1.4 VVT-i (ZZE120_), TOYOTA COROLLA (ZZE12_, NDE12_, ZDE12_) 1.8 4WD (ZZE124), TOYOTA AVENSIS (T25_) 1.8 VVT-i (ZZT251_), TOYOTA AVENSIS (T25_) 1.6 VVT-i (ZZT250_), TOYOTA RAV 4 II (CLA2_, XA2_, ZCA2_, ACA2_) 1.8 (ZCA25_, ZCA26_), TOYOTA AVENSIS Saloon (T25) 1.8 VVT-i (ZZT251_), TOYOTA AVENSIS Saloon (T25) 1.6 VVT-i (ZZT250_), TOYOTA CELICA (ZZT23_) 1.8 16V VT-i (ZZT230_), TOYOTA CELICA (ZZT23_) 1.8, TOYOTA COROLLA Verso (ZER_, ZZE12_, R1_) 1.6 (ZNR10_), TOYOTA COROLLA Verso (ZER_, ZZE12_, R1_) 1.8 (ZZE122), TOYOTA COROLLA Verso (ZER_, ZZE12_, R1_) 1.8 (ZNR11_), TOYOTA AVENSIS Estate (T25) 1.6 VVT-i (ZZT250_), TOYOTA AVENSIS Estate (T25) 1.8 VVT-i (ZZT251_), TOYOTA Yaris Hatchback (_P13_) 1.3 (NCP130_), TOYOTA LAND CRUISER (KDJ12_, GRJ12_) 2.7 (RZJ120, RZJ125), TOYOTA AVENSIS (_T22_) 1.6 VVT-i (ZZT220_), TOYOTA AVENSIS (_T22_) 1.8 VVT-i (ZZT221_), TOYOTA MR 2 III (ZZW3_) 1.8 16V VT-i (ZZW30), TOYOTA Yaris III Hatchback (XP150) 1.3 (NCP151_), TOYOTA AVENSIS Liftback (_T22_) 1.6 VVT-i (ZZT220_), TOYOTA AVENSIS Liftback (_T22_) 1.8 VVT-i (ZZT221_), TOYOTA Yaris Verso (_P2_) 1.5 4WD (NCP25), TOYOTA Yaris Verso (_P2_) 1.3 (NCP20_, NCP22_), TOYOTA Yaris Verso (_P2_) 1.3 (NCP20_, NCP22_), TOYOTA COROLLA Liftback (_E11_) 1.4 (ZZE111_), TOYOTA COROLLA Liftback (_E11_) 1.6 (ZZE112_), TOYOTA Yaris / Vios Saloon (_P9_) 1.5 (NCP93), TOYOTA Yaris / Vios Saloon (_P9_) 1.3 (NCP92_), TOYOTA Yaris / Vios Saloon (_P9_) 1.3 (NCP92_, SCP92_), TOYOTA Avensis Estate (_T22_) 1.6 VVT-i (ZZT220_), TOYOTA Avensis Estate (_T22_) 1.8 VVT-i (ZZT221_), TOYOTA MR 2 II (SW2_) 2.2 (SW21_), TOYOTA COROLLA Saloon (_E12J_, _E12T_) 1.8 (ZZE122), TOYOTA COROLLA Saloon (_E12J_, _E12T_) 1.8 (ZZE122), TOYOTA COROLLA Saloon (_E12J_, _E12T_) 1.8 (ZZE122), TOYOTA COROLLA Saloon (_E12J_, _E12T_) 1.4 VVT-i (ZZE120_), TOYOTA COROLLA Saloon (_E12J_, _E12T_) 1.3 (NZE120_), TOYOTA CARINA E Saloon (_T19_) 1.6 (AT190), TOYOTA CARINA E Saloon (_T19_) 1.6 16V (AT190_), TOYOTA COROLLA Verso (ZDE12_, CDE12_) 1.8 VVT-i (ZZE122_), TOYOTA COROLLA Verso (ZDE12_, CDE12_) 1.6 VVT-i (ZZE121_), TOYOTA COROLLA Verso (ZDE12_, CDE12_) 1.8 VVTi 4WD (ZZE126_, ZZE124), TOYOTA COROLLA (_E11_) 1.6 4WD (AE114), TOYOTA COROLLA (_E11_) 1.6 16V (ZZE112_), TOYOTA COROLLA (_E11_) 1.4 16V (ZZE111_), TOYOTA CARINA E (_T19_) 1.6 16V (AT190_), TOYOTA CARINA E (_T19_) 1.6 GLI (AT190), TOYOTA CELICA Coupe (AT18_, ST18_) 2.2 (ST184), TOYOTA COROLLA Compact (_E11_) 1.6 (ZZE112_), TOYOTA COROLLA Saloon (E15_) 1.6 VVTi (ZZE141_), TOYOTA COROLLA Saloon (E15_) 1.6 VVTi (ZZE141), TOYOTA COROLLA Compact (_E11_) 1.4 (ZZE111_), TOYOTA COROLLA Estate (_E12J_, _E12T_) 1.8 (ZZE122), TOYOTA COROLLA Estate (_E12J_, _E12T_) 1.6 VVT-i (ZZE121_), TOYOTA COROLLA Estate (_E12J_, _E12T_) 1.4 VVT-i (ZZE120_), TOYOTA COROLLA Estate (_E12J_, _E12T_) 1.5 (NZE121_), TOYOTA Vios / Yaris III Saloon (XP150) 1.3 (NCP151_), TOYOTA Vios / Yaris III Saloon (XP150) 1.3 (NCP151_), TOYOTA COROLLA (_E10_) 1.6 (AE101), TOYOTA COROLLA (_E10_) 1.6 (AE101_), TOYOTA COROLLA (_E10_) 1.5 (AE100), TOYOTA COROLLA (_E10_) 1.6 (AE101), TOYOTA Corolla Estate (_E11_) 1.6 16V (ZZE112_), TOYOTA Corolla Estate (_E11_) 1.4 16V (ZZE111_), TOYOTA COROLLA Compact (_E10_) 1.6 i (AE101), TOYOTA CARINA E Sportswagon (_T19_) 1.6 (AT190), TOYOTA CARINA E Sportswagon (_T19_) 1.6 GLI (AT190_), TOYOTA bB I (NCP3_) 1.5 (NCP31), TOYOTA Wish MPV (_E1_) 1.8 Hi 4WD (ZNE14G), TOYOTA Wish MPV (_E1_) 1.8 Hi (ZNE10), TOYOTA PASEO Coupe (EL44_) 1.5 (EL44), TOYOTA PRIUS Saloon (_W1_) 1.5 Hybrid (NHW10), TOYOTA bB I (NCP3_) 1.3 (NCP30_) View more

The steps may slightly vary depending on the car design.

How to change spark plug on TOYOTA YARIS XP10 TUTORIAL | AUTODOC

video
Tools
Replacement: spark plugs – Toyota Yaris P1. Tools you might need:
Electronic spray
High-temperature anti-seize lubricant
Drive socket # 10
Spark plug socket # 16
Ratchet wrench
Torque wrench
Flat Screwdriver
Fender cover
Replacement: spark plugs – Toyota Yaris P1. Tip from AUTODOC:
  • The replacement procedure is the same for all spark plugs.
  • All work should be done with the engine stopped.
Replacement: spark plugs – Toyota Yaris P1. Use the following procedure:
  1. Step 1
    How to change Spark Plug on Toyota Yaris Mk1 2006 - free PDF and video manuals
    Open the bonnet.
  2. Step 2
    Use a fender protection cover to prevent damaging paintwork and plastic parts of the car.
    Step 3
    How to replace TOYOTA Yaris Hatchback (_P1_) 1.0 (SCP10_) 2007 Spark Plug - step-by-step manuals and video guides
    Unscrew the engine cover fastener. Use a drive socket #10. Use a ratchet wrench.
  3. Step 4
    Toyota Yaris Mk1 1.4 D-4D (NLP10_) 2008 Spark Plug replacement: free workshop manuals
    Remove the engine cover.
  4. Step 5
    Changing Spark Plug on TOYOTA Yaris Hatchback (_P1_) 1.3 (NCP10_, SCP12_) 2009 by yourself
    Unplug the connectors from the ignition coils. Use a flat screwdriver.
  5. Step 6
    How to remove TOYOTA YARIS 1.5 (NCP13_) 2010 Spark Plug - online easy-to-follow instructions
    Unscrew the fasteners of the ignition coils. Use a drive socket #10. Use a ratchet wrench.
  6. Step 7
    How to replace Spark Plug on TOYOTA Yaris Hatchback (_P1_) 2011: download PDF manuals and video instructions
    Take out the ignition coils from the spark plug wells.
  7. Step 8
    Clean dirt, dust and debris from inside the spark plug wells.
    Step 9
    How hard is it to do yourself: Spark Plug replacement on Toyota Yaris Mk1 1.3 4WD (NCP15) 2012 - download illustrated guide
    Unscrew the spark plugs. Use the spark plug socket #16. Use a ratchet wrench.
  8. Step 10
    Need to know how to renew Spark Plug on TOYOTA YARIS 2006? This free workshop manual will help you to do it yourself
    Take out the spark plugs. Use the spark plug socket #16.
  9. Step 11
    Changing of Spark Plug on Toyota Yaris Mk1 2007 won't be an issue if you follow this illustrated step-by-step guide
    Apply a thin layer of a special high temperature anti-seize lubricant to the threads of the new spark plugs.
  10. Step 12
    TOYOTA YARIS 1.4 D-4D (NLP10_) Spark Plug replacement: online guides and video tutorials
    Install the new spark plugs into their mounting seats.
  11. Step 13
    Replacing Spark Plug on Toyota Yaris Mk1 2009 1.0 (SCP10_) by yourself
    Screw new spark plugs and tighten them. Use the spark plug socket #16. Use a torque wrench. Tighten it to 22 nm torque.
    Replacement: spark plugs – Toyota Yaris P1. AUTODOC recommends:
    Don't tighten the plugs with excessive force. Exceeding tightening torque can damage the thread connection. Be careful when working with a spark plug wrench. Its skewing can cause damage to the threaded connection.
