Replace the brake disks on the car Honda CR-V II in complete set for each axis. Regardless of the state of components. This will ensure even braking.
The replacement procedure is identical for both brake disks on the same axle.
When changing the brake discs, always replace the brake pads.
Please note: all work on the car – Honda CR-V II – should be done with the engine switched off.
Carry out replacement in the following order:
Step 1
Open the bonnet. Unscrew the brake fluid reservoir cap.
Step 2
Secure the wheels with chocks.
Step 3
Loosen the wheel mounting bolts. Use wheel impact socket #19.
Step 4
Raise the rear of the car and secure on supports.
Step 5
Unscrew the wheel bolts.
AUTODOC recommends:
Warning! To avoid injury, hold the wheel while unscrewing the fastening bolts. Honda CR-V II
Step 6
Remove the wheel.
Step 7
Clean the brake caliper fasteners. Use a wire brush. Use WD-40 spray.
Step 8
Unscrew the brake caliper fastening. Use a combination spanner #17. Use a drive socket #12. Use a ratchet wrench.
Step 9
Spread the brake pads. Use a crowbar.
Step 10
Remove the brake caliper. Use a crowbar.
Replacement: brake pads – Honda CR-V II. AUTODOC experts recommend:
Tie the caliper to the suspension or to the body with a wire without disconnecting from the brake hose to prevent depressurization of the brake system.Make sure that the brake caliper is not hanging on the brake hose.Don't press the brake pedal after the brake caliper has been removed. As a result, the piston can fall out from the brake cylinder, and brake fluid leakage and depressurization of the system may occur. Check the brake caliper bracket, brake caliper guide pins and boots. Clean them. Replace, if necessary.
Step 11
Remove the brake pads. Use a crowbar.
Replacement: brake pads – Honda CR-V II. AUTODOC recommends:
Measure the brake disc thickness. Upon reaching the wear limit the part must be replaced.
Step 12
Clean the brake caliper bracket from dirt and dust. Use a wire brush. Use a brake cleaner.
AUTODOC recommends:
Replacement: brake pads – Honda CR-V II. After applying the spray, wait a few minutes.
Step 13
Treat the brake caliper piston. Use a brake cleaner.
AUTODOC recommends:
After applying the spray, wait a few minutes.
Step 14
Press in the brake caliper piston. Use brake caliper wind back tool.
Step 15
Treat the brake pads in the area where their surface comes into contact with the brake caliper bracket. Use anti-squeal paste.
Replacement: brake pads – Honda CR-V II. Tip from AUTODOC:
Make sure the disc surface is clean before installing the pads.
Step 16
Install new brake pads.
AUTODOC recommends:
Make sure the pads are installed with linings facing the disc.
Step 17.1
Install the brake caliper and fix it.
Step 17.2
Use a combination spanner #17. Use a drive socket #12. Use a torque wrench. Tighten it to 22 Nm torque.
Step 18
Treat the surface where the brake disc contacts the wheel rim. Use copper grease.
Step 19
Clean the brake disk surface. Use a brake cleaner.
AUTODOC recommends:
Replacement: brake pads – Honda CR-V II. After applying the spray, wait a few minutes.
Step 20
Install the wheel.
AUTODOC recommends:
Warning! To avoid injury, hold the wheel while screwing in the fastening bolts on the car. Honda CR-V II
Step 21
Screw in the wheel bolts. Use wheel impact socket #19.
Step 22
Lower the car and working in a cross order, tighten the wheel bolts. Use wheel impact socket #19. Use a torque wrench. Tighten it to 108 nm torque.
Step 23
Remove the jacks and chocks.
Replacement: brake pads – Honda CR-V II. AUTODOC experts recommend:
Check the brake fluid level in the expansion tank and refill if necessary.
Step 24
Tighten the brake fluid reservoir cap. Close the hood.
Replacement: brake pads – Honda CR-V II. Tip from AUTODOC experts:
Without starting the engine, press the brake pedal several times until you feel significant resistance.Slow down smoothly for first 150-200 km after the brake pads replacement. Avoid unneccessary and sharp braking to a stop.
