Important!

This replacement procedure can be used for:
NISSAN MICRA II (K11) 1.3 i 16V

The steps may slightly vary depending on the car design.

How to change front strut mount on NISSAN MICRA 2 Hatchback [TUTORIAL AUTODOC]

Replacement: strut mount – Nissan Micra K11. Tools you might need:

                        Wire brush

                        WD-40 spray

                        Brake cleaner

                        Copper grease

                        Drive socket # 12

                        Drive socket # 17

                        Combination spanner #14

                        Combination spanner #17

                        Wheel impact socket #19

                        Ratchet wrench

                        Torque wrench

                        Adjustable wrench

                        Hydraulic strut spring compressor

                        Pliers

                        Rubber mallet

                        Crow bar

                        Fender cover

                        Wheel chock

All the parts you need to replace – Strut Mount for MICRA II (K11) and other NISSAN models

NISSAN MICRA II (K11) 1.3 i 16V

Replacement: strut mount – Nissan Micra K11. Tip from AUTODOC:

The replacement procedure is identical for the mounts of the left and right shock struts of the front suspension.
All mounts of the front shock struts should be replaced simultaneously.
Please note: all work on the car – Nissan Micra K11 – should be done with the engine switched off.

Carry out replacement in the following order:

Step 1

Secure the wheels with chocks.
Step 2

Loosen the wheel mounting bolts.Use wheel impact socket #19.
Step 3

Raise the front of the car and secure on supports.
Step 4

Unscrew the wheel bolts.

AUTODOC recommends:

Warning! To avoid injury, hold the wheel while unscrewing the fastening bolts. Nissan Micra K11
Step 5

Remove the wheel.
Step 6

Take out the retainer clip and move the brake hose out of the bracket on the shock strut.Use pliers.
Step 7

Clean the fasteners connecting the shock strut to the steering knuckle.Use a wire brush.Use WD-40 spray.

Step 8

Unscrew the fasteners connecting the suspension strut to the steering knuckle.Use a combination spanner #17.Use a drive socket #17.Use a ratchet wrench.
Step 9

Remove the fastening bolts (2 pieces).

Step 10

Disconnect the steering knuckle from the shock absorber strut.Use a crowbar.
Step 11

Lower the car.
Step 12

Open the bonnet.
Step 13

Use a fender protection cover to prevent damaging paintwork and plastic parts of the car.

Step 14

Clean the fasteners of the shock strut upper mount.Use a wire brush.Use WD-40 spray.

Step 15

Unscrew the upper fasteners of the shock strut (3 pieces).Use a drive socket #E12.Use a ratchet wrench.

AUTODOC recommends:

Important! Hold the suspension strut while unscrewing the fastening bolts. Nissan Micra K11
Step 16

Remove the suspension strut.
Step 17

Set the shock absorber strut on the spring compressor tool.

Replacement: strut mount – Nissan Micra K11. Tip:

Note that when using a spring compressor, spring coils need to be securely gripped, compressing the spring on the opposite sides.Ensure the correct position of the spring in the retainer.Make sure that the spring coils tightly entered the lock handles.
Step 18

Compress the spring.
Step 19

Clean the upper fastener of the suspension strut mount.Use a wire brush.Use WD-40 spray.

Step 20

Unscrew the top fastening of the shock strut mount.Use a combination spanner #14.Use an adjustable wrench.
Step 21

Remove the top strut mount.

Replacement: strut mount – Nissan Micra K11. Professionals recommend:

Examine the shock absorber dust cap and the bump stop. Replace them if necessary.
Step 22

Install a new top shock strut mount.
Step 23

Tighten the upper fastener of the shock absorber strut mount.Use a combination spanner #14.Use an adjustable wrench.Use a torque wrench.Tighten it to 60 Nm torque.

Replacement: strut mount – Nissan Micra K11. AUTODOC experts recommend:

Check to make sure the spring is positioned correctly. Avoid its misalignment.
Step 24

Treat the shock strut rod.Use copper grease.
Step 25

Decompress the spring.

Step 26

Remove the assembled shock strut.
Step 27

Install the shock strut into the wheel arch.
Step 28

Secure the upper fasteners of the shock strut (3 pieces).

AUTODOC recommends:

Important! Hold the suspension strut while screwing in the fastening bolts. Nissan Micra K11
Step 29

Tighten the upper fasteners of the shock strut (3 pieces).Use a drive socket #12.Use a torque wrench.Tighten it to 50 Nm torque.
Step 30

Remove the fender protection cover.

Step 31

Close the hood.
Step 32

Raise the front of the car and secure on supports.
Step 33

Treat the shock strut mounting seat on the steering knuckle.Use a wire brush.Use WD-40 spray.

Step 34

Fix the shock absorber strut on the steering knuckle.

Step 35

Install the fastening bolts (2 pieces).
Step 36

Tighten the lower fasteners connecting the shock strut to the steering knuckle.Use a combination spanner #17.Use a drive socket #17.Use a torque wrench.Tighten it to 80 Nm torque.
Step 37

Fasten the brake hose on the strut.

Step 38

Attach the brake hose retainer clip.Use a rubber mallet.
Step 39

Treat the shock strut fasteners.Use copper grease.
Step 40

Treat the surface where the brake disc contacts the wheel rim. Use copper grease.
Step 41

Clean the brake disk surface.Use a brake cleaner.

AUTODOC recommends:

Replacement: strut mount – Nissan Micra K11. After applying the spray, wait a few minutes.
Step 42

Install the wheel.

AUTODOC recommends:

Warning! To avoid injury, hold the wheel while screwing in the fastening bolts on the car. Nissan Micra K11
Step 43

Screw in the wheel bolts.Use wheel impact socket #19.
Step 44

Lower the car and working in a cross order, tighten the wheel bolts.Use wheel impact socket #19.Use a torque wrench.Tighten it to 120 Nm torque.
Step 45

Remove the jacks and chocks.
