When to replace the Brake Pads on your AUDI A4
Recommended replacement interval for the part category Brake pad set : 30000 km
Important!
This replacement procedure can be used for:
AUDI A4 Avant (8ED, B7) 2.0 TDI quattro, AUDI A4 Avant (8ED, B7) 2.0 TDI, AUDI A4 Avant (8ED, B7) 1.6, AUDI A4 Avant (8ED, B7) 2.0, AUDI A4 Avant (8ED, B7) 1.8 T, AUDI A4 Avant (8ED, B7) 1.8 T quattro, AUDI A4 Avant (8ED, B7) 1.9 TDI, AUDI A4 Avant (8ED, B7) 2.0 TDI 16V, AUDI A4 Avant (8ED, B7) 2.5 TDI, AUDI A4 Avant (8ED, B7) 2.0 TFSI, AUDI A4 Avant (8ED, B7) 2.0 TFSI quattro, AUDI A4 Avant (8ED, B7) 2.0 TDI, AUDI A4 Avant (8ED, B7) 2.0 TDI quattro, AUDI A4 Avant (8ED, B7) 2.0 TDI, AUDI A4 Avant (8ED, B7) 2.0 TFSI, AUDI A4 Avant (8ED, B7) 2.0 TDI, AUDI A4 Avant (8ED, B7) 2.0 TDI quattro, AUDI A4 Avant (8ED, B7) 2.7 TDi, AUDI A4 Avant (8ED, B7) 2.0 TDI … View more

The steps may slightly vary depending on the car design.

How to change rear brake discs and rear brake pads on AUDI A4 B7 AVANT TUTORIAL | AUTODOC

video
Published on: 08/12/2016
37K views
All the parts you need to replace – Brake Pads for A4 Avant (8ED, B7) and other AUDI models
Alternative products
How to change Brake pad set on Audi A4 B7 Avant 2.0 TDI – step-by-step instructions for straightforward car repair Brake pad set
Tools
Replacement: brake pads – Audi A4 B7 Avant. Tools you might need:
Wire brush
WD-40 spray
Brake cleaner
Anti-squeal paste
Copper grease
Sealant
Combination spanner #13
Combination spanner #16
Wheel impact socket #17
Brake caliper wind back tool
Ratchet wrench
Torque wrench
Flat Screwdriver
Crow bar
Wheel chock
Buy tools
Replacement: brake pads – Audi A4 B7 Avant. AUTODOC recommends:
  • Perform the replacement of brake pads in complete set for each axis. This provides effective braking.
  • The replacement procedure is identical for all brake pads on the same axle.
  • Warning! Shut down the engine before starting any work – Audi A4 B7 Avant.
Carry out replacement in the following order:
  1. Step 1
    How to change Brake Pads on Audi A4 B7 Avant 2004 - free PDF and video manuals
    Open the bonnet. Unscrew the brake fluid reservoir cap.
  2. Step 2
    How to replace AUDI A4 Avant (8ED, B7) 2.0 TDI 2005 Brake Pads - step-by-step manuals and video guides
    Secure the wheels with chocks.
  3. Step 3
    Audi A4 B7 Avant 2.0 TDI 16V 2006 Brake Pads replacement: free workshop manuals
    Loosen the wheel mounting bolts. Use wheel impact socket #17.
  4. Step 4
    Changing Brake Pads on AUDI A4 Avant (8ED, B7) 2.0 TDI quattro 2007 by yourself
    Raise the rear of the car and secure on supports.
  5. Step 5
    How to remove AUDI A4 2.0 TFSI quattro 2008 Brake Pads - online easy-to-follow instructions
    Unscrew the wheel bolts.
    Replacement: brake pads – Audi A4 B7 Avant. AUTODOC experts recommend:
    To avoid injury, hold up the wheel when unscrewing the bolts.
  6. Step 6
    How to replace Brake Pads on AUDI A4 Avant (8ED, B7) 2004: download PDF manuals and video instructions
    Remove the wheel.
  7. Step 7
    How hard is it to do yourself: Brake Pads replacement on Audi A4 B7 Avant 1.8 T 2005 - download illustrated guide
    Clean the brake caliper fasteners. Use a wire brush. Use WD-40 spray.
  8. Step 8
    Need to know how to renew Brake Pads on AUDI A4 2006? This free workshop manual will help you to do it yourself
    Unscrew the brake caliper fastening Use a combination spanner #13. Use a combination spanner #16.
  9. Step 9
    Remove the fastening bolts (2 pieces).
    Step 10
    Changing of Brake Pads on Audi A4 B7 Avant 2007 won't be an issue if you follow this illustrated step-by-step guide
    Spread the brake pads. Use a crowbar.
  10. Step 11
    AUDI A4 2.0 TDI 16V Brake Pads replacement: online guides and video tutorials
    Remove the brake caliper. Use a flat screwdriver.
    Replacement: brake pads – Audi A4 B7 Avant. Tip from AUTODOC:
    Tie the caliper to the suspension or to the body with a wire without disconnecting from the brake hose to prevent depressurization of the brake system.Make sure that the brake caliper is not hanging on the brake hose.Don't press the brake pedal after the brake caliper has been removed. As a result, the piston can fall out from the brake cylinder, and brake fluid leakage and depressurization of the system may occur. Check the brake caliper bracket, brake caliper guide pins and boots. Clean them. Replace, if necessary.
  11. Step 12
    Replacing Brake Pads on Audi A4 B7 Avant 2004 2.0 TDI by yourself
    Remove the brake pads.
    Replacement: brake pads – Audi A4 B7 Avant. Tip:
    Measure the brake disc thickness. Upon reaching the wear limit the part must be replaced.
  12. Step 13
    A4 Avant (8ED, B7) 2.0 TFSI quattro 2005 Brake Pads DIY replacement workshop manual
    Clean the brake caliper bracket from dirt and dust. Use a wire brush. Use a brake cleaner.
    AUTODOC recommends:
    Replacement: brake pads – Audi A4 B7 Avant. After applying the spray, wait a few minutes.
  13. Step 14
    How to change Brake Pads on AUDI A4 Avant (8ED, B7) 2006 - tips and tricks
    Treat the brake caliper piston. Use a brake cleaner.
    Replacement: brake pads – Audi A4 B7 Avant. Tip from AUTODOC:
    After applying the spray, wait a few minutes.
  14. Step 15
    Step-by-step recommendations for DIY replacement Audi A4 B7 Avant 2007 2.0 TFSI quattro Brake Pads
    Press in the brake caliper piston. Use brake caliper wind back tool.
  15. Step 16
    DIY replacement of Brake Pads on AUDI A4 Avant (8ED, B7) 1.9 TDI 2008 is not an issue anymore with our step-by-step tutorial
    Treat the brake pads in the area where their surface comes into contact with the brake caliper bracket. Use anti-squeal paste.
    Replacement: brake pads – Audi A4 B7 Avant. Tip:
    Make sure the disc surface is clean before installing the pads.
