How to change fuel filter on Opel Meriva X03 – replacement guide
downloads:
16
Views:
443
0
Users voted – 0
Recommended replacement interval for the part category Fuel filter : 2year / 30000km
Important!
This replacement procedure can be used for:
OPEL Meriva A (X03) 1.4 16V Twinport LPG (E75),
OPEL Meriva A (X03) 1.8 (E75),
OPEL Meriva A (X03) 1.6 (E75),
OPEL Meriva A (X03) 1.4 16V Twinport (E75),
OPEL Meriva A (X03) 1.6 (E75),
OPEL Meriva A (X03) 1.6 Turbo (E75)
…
View more
The steps may slightly vary depending on the car design.
How to change fuel filter OPEL MERIVA A [TUTORIAL AUTODOC]
All the parts you need to replace – Fuel Filter for Meriva A (X03) and other OPEL models
Replacement: fuel filter – Opel Meriva X03. AUTODOC recommends:
Ensure adequate ventilation of the workplace. Fuel vapors are poisonous.
All work should be done with the engine stopped.
Replacement: fuel filter – Opel Meriva X03. Recommended sequence of steps:
Step 1
Open the fuel door.
Step 2
Unscrew the fuel filler cap.
Step 3
Lift the car using a jack or place it over an inspection pit.
Step 4
Prepare a container for fluids.
Step 5
Clean the fasteners of the fuel supply lines. Use a nylon cleaning brush. Use all-purpose cleaning spray.
Step 6
Disconnect the fuel supply lines from the fuel filter. Use fuel line pliers. Use a crowbar.
Replacement: fuel filter – Opel Meriva X03. Tip from AUTODOC experts:
Be careful! Fuel may leak from the filter housing and hoses.
Step 7
Unscrew the fuel filter bracket. Use a Phillips screwdriver.
Step 8
Remove the fuel filter. Use a crowbar.
Step 9
Put the old filter cartridge in the container.
Step 10
Install a new fuel filter.
Replacement: fuel filter – Opel Meriva X03. AUTODOC experts recommend:
Remember, it is important not to mix up the input and output of the filter. Arrows on the filter indicate the direction of fuel flow.During installation, take care to prevent dust and dirt from getting into the fuel filter housing.Opel Meriva X03 – It's important to only use high-quality filters.
Step 11
Connect the fuel supply lines to the fuel filter.
Step 12
Screw in the fuel filter mounting bracket. Use a Phillips screwdriver.
Step 13
Clean the fasteners of the fuel supply lines. Use all-purpose cleaning spray.
Step 14
Take the fluid container away from under the fuel filter.
Step 15
Lower the car.
Step 16
Tighten the fuel filler cap.
Step 17
Close the fuel door.
Replacement: fuel filter – Opel Meriva X03. Professionals recommend:
Before starting off, switch the ignition on and off several times. This should be done to activate the fuel pump to make it pump fuel through the fuel system.
Step 18
Run the engine for a few minutes. This is necessary in order to make sure that the component operates properly.
Step 19
Shut off the engine.
Replacement: fuel filter – Opel Meriva X03. Tip:
To protect the environment from pollution, be sure to dispose of the used filters at special collection points.
