Recommended replacement interval for the part category Brake pad set : 30000 km

Important!

This replacement procedure can be used for:
AUDI A4 Saloon (8D2, B5) 1.6 … View more

The steps may slightly vary depending on the car design.

How to change front brake pads on AUDI A4 B5 Saloon [TUTORIAL AUTODOC]

All the parts you need to replace – Brake Pads for A4 Saloon (8D2, B5) and other AUDI models

Brake pad set

Brake pad set for A4 B5 Saloon (8D2) Petrol (102 hp)

Replacement: brake pads – Audi A4 B5 saloon. Tools you might need:

                        Wire brush

                        Nylon cleaning brush

                        WD-40 spray

                        Brake cleaner

                        Anti-squeal paste

                        Copper grease

                        Torque wrench

                        Combination spanner #15

                        Drive socket # 13

                        Wheel impact socket #17

                        Ratchet wrench

                        Brake caliper wind back tool

                        Crow bar

                        Wheel chock

Buy tools

Replacement: brake pads – Audi A4 B5 saloon. AUTODOC experts recommend:

Perform the replacement of brake pads in complete set for each axis. This provides effective braking.
The replacement procedure is identical for all brake pads on the same axle.
All work should be done with the engine stopped.

Replacement: brake pads – Audi A4 B5 saloon. Use the following procedure:

Step 1

Open the hood. Unscrew the brake fluid reservoir cap.
Step 2

Secure the wheels with chocks.

Step 3

Loosen the wheel mounting bolts. Use wheel impact socket #17.
Step 4

Raise the front of the car and secure on supports.
Step 5

Unscrew the wheel bolts.

AUTODOC recommends:
Warning! To avoid injury, hold the wheel while unscrewing the fastening bolts. Audi A4 B5 saloon
Step 6

Remove the wheel.

Step 7

Spread the brake pads. Use a crowbar.
Step 8

Disconnect the ABS sensor wiring.
Step 9

Clean the brake caliper fasteners. Use a wire brush. Use WD-40 spray.
Step 10

Unscrew the brake caliper fastening. Use a combination spanner #15. Use a drive socket #13. Use a ratchet wrench.
Step 11

Remove the brake caliper. Use a crowbar.

Replacement: brake pads – Audi A4 B5 saloon. Tip from AUTODOC:
Tie the caliper to the suspension or to the body with a wire without disconnecting from the brake hose to prevent depressurization of the brake system.Make sure that the brake caliper is not hanging on the brake hose.Don't press the brake pedal after the brake caliper has been removed. As a result, the piston can fall out from the brake cylinder, and brake fluid leakage and depressurization of the system may occur.Check the brake caliper bracket, brake caliper guide pins and boots. Clean them. Replace, if necessary.
Step 12

Remove the brake pads.

Replacement: brake pads – Audi A4 B5 saloon. AUTODOC recommends:
Measure the brake disc thickness. Upon reaching the wear limit the part must be replaced.
Step 13

Clean the brake caliper bracket from dirt and dust. Use a wire brush. Use a brake cleaner.

AUTODOC recommends:
Replacement: brake pads – Audi A4 B5 saloon. After applying the spray, wait a few minutes.
Step 14

Treat the brake caliper piston. Use a nylon cleaning brush. Use a brake cleaner.

Replacement: brake pads – Audi A4 B5 saloon. Tip from AUTODOC:
After applying the spray, wait a few minutes.
Step 15

Press in the brake caliper piston. Use brake caliper wind back tool.
Step 16

Treat the brake pads in the area where their surface comes into contact with the brake caliper bracket. Use anti-squeal paste.

Replacement: brake pads – Audi A4 B5 saloon. AUTODOC experts recommend:
Make sure the disc surface is clean before installing the pads.
Step 17

Install new brake pads.

Replacement: brake pads – Audi A4 B5 saloon. Professionals recommend:
Make sure the pads are installed with linings facing the disc.
Step 18

Install the brake caliper and fix it. Use a combination spanner #15. Use a drive socket #13. Use a torque wrench. Tighten it to 30 Nm torque.
Step 19

Connect the ABS sensor wiring.
Step 20

Clean the wheel rim mounting seat. Use a wire brush.
Step 21

Treat the surface where the brake disc contacts the wheel rim. Use copper grease.

Step 22

Clean the brake disk surface. Use a brake cleaner.

AUTODOC recommends:
Replacement: brake pads – Audi A4 B5 saloon. After applying the spray, wait a few minutes.
Step 23

Install the wheel.

AUTODOC recommends:
Important! Hold the wheel while screwing in the fastening bolts. Audi A4 B5 saloon
Step 24

Screw in the wheel bolts. Use wheel impact socket #17.
Step 25

Lower the car and working in a cross order, tighten the wheel bolts. Use wheel impact socket #17. Use a torque wrench. Tighten it to 120 nm torque.
Step 26

Remove the jacks and chocks.

Replacement: brake pads – Audi A4 B5 saloon. Tip from AUTODOC:
Without starting the engine, press the brake pedal several times until you feel significant resistance.Check the brake fluid level in the expansion tank and refill if necessary.
Step 27

Tighten the brake fluid reservoir cap. Close the hood.

Replacement: brake pads – Audi A4 B5 saloon. AUTODOC recommends:
Slow down smoothly for first 150-200 km after the brake pads replacement. Avoid unneccessary and sharp braking to a stop.
