How to carry out replacement: Anti Roll Bar Links 2.0 TDI Passat B6 Variant
Disclaimer
Change Passat B6 Variant 2.0 TDI Anti Roll Bar Links yourself – manuals and video tutorials

How to change front anti roll bar links on VW Passat 3C B6 Variant – replacement guide

downloads: 2
Views: 108
Download your free tutorial and fix VW Passat Variant (3C5) 1.6 TDI problems yourself Download for free 1.43 MB Anti Roll Bar Links for Passat B6 Variant Shop now
Leave a comment Open in a new tab
Important!
This replacement procedure can be used for:
VW Passat Variant (3C5) 2.0 TDI, VW Passat Variant (3C5) 1.6 FSI, VW Passat Variant (3C5) 2.0 FSI, VW Passat Variant (3C5) 1.9 TDI, VW Passat Variant (3C5) 2.0 TDI 16V, VW Passat Variant (3C5) 1.6, VW Passat Variant (3C5) 2.0 TDI, VW Passat Variant (3C5) 2.0 TDI, VW Passat Variant (3C5) 2.0 TDI, VW Passat Variant (3C5) 2.0 TFSI, VW Passat Variant (3C5) 3.2 FSI 4motion, VW Passat Variant (3C5) 2.0 TDI 16V 4motion, VW Passat Variant (3C5) 2.0 FSI 4motion, VW Passat Variant (3C5) 2.0 TDI 4motion, VW Passat Variant (3C5) 3.6 R36 4motion, VW Passat Variant (3C5) 1.4 TSI, VW Passat Variant (3C5) 1.8 TSI, VW Passat Variant (3C5) 3.6 FSI, VW Passat Variant (3C5) 2.0 TDI, VW Passat Variant (3C5) 1.4 TSI EcoFuel, VW Passat Variant (3C5) 2.0 TDI, VW Passat Variant (3C5) 2.0 BlueTDI, VW Passat Variant (3C5) 1.6 TDI, VW Passat Variant (3C5) 2.0 TDI 4motion, VW Passat Variant (3C5) 1.8 TSI … View more

The steps may slightly vary depending on the car design.

How to change front anti roll bar link / front drop link on VW PASSAT B6 (3C5) [TUTORIAL AUTODOC]

video
Published on: 13/04/2020
5K views
All the parts you need to replace – Anti Roll Bar Links for Passat Variant (3C5) and other VW models
How to change Anti-roll bar link on Passat B6 Variant 2.0 TDI – step-by-step instructions for straightforward car repair Anti-roll bar link
How to change Anti-roll bar link on Passat B6 Variant (3C5) – tips for proper car maintenance
Anti-roll bar link for Passat B6 Variant (3C5) Diesel (120 hp)
Simple DIY car repair steps – Replacing Anti-roll bar link on Passat B6 Variant (3C5)
Anti-roll bar link for Passat B6 Variant (3C5) Petrol (115 hp)
Easy tricks to help you to replace Anti-roll bar link on Passat B6 Variant (3C5)
Anti-roll bar link for Passat B6 Variant (3C5) Petrol (150 hp)
Anti-roll bar link removal & installation, incredibly easy steps for Passat B6 Variant (3C5)
Anti-roll bar link for Passat B6 Variant (3C5) Diesel (105 hp)
Changing Anti-roll bar link on Passat B6 Variant (3C5) – tips for first time repair
Anti-roll bar link for Passat B6 Variant (3C5) Diesel (140 hp)
Main steps for Anti-roll bar link replacement on Passat B6 Variant (3C5)
Anti-roll bar link for Passat B6 Variant (3C5) Petrol (102 hp)
How to change Anti-roll bar link on Passat B6 Variant (3C5) – tips for proper car maintenance
Anti-roll bar link for Passat B6 Variant (3C5) Diesel (122 hp)
Simple DIY car repair steps – Replacing Anti-roll bar link on Passat B6 Variant (3C5)
Anti-roll bar link for Passat B6 Variant (3C5) Diesel (136 hp)
Easy tricks to help you to replace Anti-roll bar link on Passat B6 Variant (3C5)
Anti-roll bar link for Passat B6 Variant (3C5) Diesel (170 hp)
Tools
Replacement: anti roll bar links – Passat Variant B6. Tools you'll need:
Wire brush
WD-40 spray
Brake cleaner
Copper grease
Combination spanner #18
Drive socket # 18
HEX bit no.H5.
Wheel impact socket #17
Ratchet wrench
Torque wrench
Wheel chock
Buy tools
Replacement: anti roll bar links – VW Passat 3C5. AUTODOC recommends:
  • Replace the stabiliser links on VW Passat 3C B6 Variant in pairs.
  • The replacement procedure is identical for both stabiliser links on the same axle.
  • Please note: all work on the car – Passat B6 3C Variant – should be done with the engine switched off.
Carry out replacement in the following order:
  1. Step 1
    How to change Anti Roll Bar Links on Passat B6 Variant 2005 - free PDF and video manuals
    Secure the wheels with chocks.
  2. Step 2
    How to replace VW Passat Variant (3C5) 2.0 TDI 2006 Anti Roll Bar Links - step-by-step manuals and video guides
    Loosen the wheel mounting bolts. Use wheel impact socket #17.
  3. Step 3
    Passat B6 Variant 2.0 TDI 16V 2007 Anti Roll Bar Links replacement: free workshop manuals
    Raise the front of the car and secure on supports.
  4. Step 4
    Changing Anti Roll Bar Links on VW Passat Variant (3C5) 2.0 FSI 2008 by yourself
    Unscrew the wheel bolts.
    Replacement: anti roll bar links – VW Passat 3C5. AUTODOC experts recommend:
    To avoid injury, hold up the wheel when unscrewing the bolts.
  5. Step 5
    How to remove VW PASSAT 2.0 TDI 4motion 2009 Anti Roll Bar Links - online easy-to-follow instructions
    Remove the wheel.
  6. Step 6
    How to replace Anti Roll Bar Links on VW Passat Variant (3C5) 2010: download PDF manuals and video instructions
    Clean the stabiliser link fasteners. Use a wire brush. Use WD-40 spray.
  7. Step 7
    How hard is it to do yourself: Anti Roll Bar Links replacement on Passat B6 Variant 1.4 TSI EcoFuel 2011 - download illustrated guide
    Unscrew the fastener connecting the stabilizer link to the shock strut. Use a drive socket #18. Use a ratchet wrench.
  8. Step 8
    Need to know how to renew Anti Roll Bar Links on VW PASSAT 2005? This free workshop manual will help you to do it yourself
    Unscrew the fastener connecting the stabilizer link to the stabilizer bar. Use a combination spanner #18. Use HEX No.H5. Use a ratchet wrench.
  9. Step 9
    Changing of Anti Roll Bar Links on Passat B6 Variant 2006 won't be an issue if you follow this illustrated step-by-step guide
    Remove the stabilizer rod.
    Replacement: anti roll bar links – Passat Variant B6. Tip from AUTODOC:
    Examine stabiliser bushes. Replace them if needed.
  10. Step 10
    VW PASSAT 2.0 TDI Anti Roll Bar Links replacement: online guides and video tutorials
    Clean the mounting seats of the stabiliser link. Use a wire brush. Use WD-40 spray.
  11. Step 11
    Replacing Anti Roll Bar Links on Passat B6 Variant 2008 2.0 TDI by yourself
    Install a new rod, tighten the fasteners.
