Important!
This replacement procedure can be used for:
SEAT Ibiza III Hatchback (6L) 1.2, SEAT Ibiza III Hatchback (6L) 1.4 16V, SEAT Ibiza III Hatchback (6L) 1.9 TDI, SEAT Ibiza III Hatchback (6L) 1.9 TDI, SEAT Ibiza III Hatchback (6L) 1.9 SDI, SEAT Ibiza III Hatchback (6L) 1.4 TDI, SEAT Ibiza III Hatchback (6L) 1.8 T Cupra R, SEAT Ibiza III Hatchback (6L) 1.8 T FR, SEAT Ibiza III Hatchback (6L) 1.6, SEAT Ibiza III Hatchback (6L) 1.9 TDI Cupra R, SEAT Ibiza III Hatchback (6L) 1.4 TDI, SEAT Ibiza III Hatchback (6L) 1.4 TDI, SEAT Ibiza III Hatchback (6L) 1.2 12V, SEAT Ibiza III Hatchback (6L) 1.6 16V, SEAT Ibiza III Hatchback (6L) 2.0 View more

The steps may slightly vary depending on the car design.

How to change front anti roll bar link on SEAT IBIZA 3 6L [TUTORIAL AUTODOC]

video
All the parts you need to replace – Anti Roll Bar Links for Ibiza III Hatchback (6L) and other SEAT models
How to change Anti-roll bar link on Seat Ibiza 6L 1.9 TDI – step-by-step instructions for straightforward car repair
Anti-roll bar link
How to change Repair Kit, stabilizer suspension on Seat Ibiza 6L 1.9 TDI – step-by-step instructions for straightforward car repair
Repair Kit, stabilizer suspension
How to change Repair Kit, stabilizer coupling rod on Seat Ibiza 6L 1.9 TDI – step-by-step instructions for straightforward car repair
Repair Kit, stabilizer coupling rod
How to change Mounting, stabilizer coupling rod on Seat Ibiza 6L 1.9 TDI – step-by-step instructions for straightforward car repair
Mounting, stabilizer coupling rod
Tools
Replacement: anti roll bar links – Seat Ibiza 6L1. Tools you'll need:
Wire brush
WD-40 spray
Brake cleaner
Copper grease
Torque wrench
Combination spanner #17
XZN socket bit # 6
Drive socket # 17
Wheel impact socket #17
Ratchet wrench
Wheel chock
Replacement: anti roll bar links – Seat Ibiza 6L1. Tip from AUTODOC:
  • Replace the stabiliser links on Seat Ibiza 6L1 in pairs.
  • The replacement procedure is identical for both stabiliser links on the same axle.
  • Warning! Shut down the engine before starting any work – Seat Ibiza 6L1
Carry out replacement in the following order:
  1. Step 1
    How to change Anti Roll Bar Links on Seat Ibiza 6L 2002 - free PDF and video manuals
    Secure the wheels with chocks.
  2. Step 2
    How to replace SEAT Ibiza III Hatchback (6L) 1.9 TDI 2003 Anti Roll Bar Links - step-by-step manuals and video guides
    Loosen the wheel mounting bolts. Use wheel impact socket #17.
  3. Step 3
    Seat Ibiza 6L 1.4 16V 2004 Anti Roll Bar Links replacement: free workshop manuals
    Raise the front of the car and secure on supports.
  4. Step 4
    Changing Anti Roll Bar Links on SEAT Ibiza III Hatchback (6L) 1.9 SDI 2005 by yourself
    Unscrew the wheel bolts.
    Replacement: anti roll bar links – Seat Ibiza 6L1. Tip:
    To avoid injury, hold up the wheel when unscrewing the bolts.
  5. Step 5
    How to remove SEAT IBIZA 1.4 TDI 2006 Anti Roll Bar Links - online easy-to-follow instructions
    Remove the wheel.
  6. Step 6
    How to replace Anti Roll Bar Links on SEAT Ibiza III Hatchback (6L) 2007: download PDF manuals and video instructions
    Clean the stabiliser link fasteners. Use a wire brush. Use WD-40 spray.
  7. Step 7
    How hard is it to do yourself: Anti Roll Bar Links replacement on Seat Ibiza 6L 1.9 TDI 2008 - download illustrated guide
    Unscrew the fastener connecting the stabilizer link to the shock strut. Use a drive socket #17. Use a ratchet wrench.
  8. Step 8
    Need to know how to renew Anti Roll Bar Links on SEAT IBIZA 2009? This free workshop manual will help you to do it yourself
    Unscrew the fasteners connecting the stabiliser link to the stabiliser bar. Use a combination spanner #17. Use XZN #6. Use a ratchet wrench.
  9. Step 9
    Changing of Anti Roll Bar Links on Seat Ibiza 6L 2002 won't be an issue if you follow this illustrated step-by-step guide
    Remove the stabilizer rod.
    Replacement: anti roll bar links – Seat Ibiza 6L1. Tip from AUTODOC:
    Examine stabiliser bushes. Replace them if needed.
  10. Step 10
    SEAT IBIZA 1.2 Anti Roll Bar Links replacement: online guides and video tutorials
    Clean the mounting seats of the stabiliser link. Use a wire brush. Use WD-40 spray.
  11. Step 11
    Replacing Anti Roll Bar Links on Seat Ibiza 6L 2004 1.9 TDI by yourself
    Ιnstall the transverse stabilizer link.
