Important!

This replacement procedure can be used for:
SEAT Ibiza III Hatchback (6L) 1.2, SEAT Ibiza III Hatchback (6L) 1.4 16V, SEAT Ibiza III Hatchback (6L) 1.9 TDI, SEAT Ibiza III Hatchback (6L) 1.9 TDI, SEAT Ibiza III Hatchback (6L) 1.9 SDI, SEAT Ibiza III Hatchback (6L) 1.4 TDI, SEAT Ibiza III Hatchback (6L) 1.8 T Cupra R, SEAT Ibiza III Hatchback (6L) 1.8 T FR, SEAT Ibiza III Hatchback (6L) 1.6, SEAT Ibiza III Hatchback (6L) 1.9 TDI Cupra R, SEAT Ibiza III Hatchback (6L) 1.4 TDI, SEAT Ibiza III Hatchback (6L) 1.4 TDI, SEAT Ibiza III Hatchback (6L) 1.2 12V, SEAT Ibiza III Hatchback (6L) 1.6 16V, SEAT Ibiza III Hatchback (6L) 2.0, SEAT Ibiza III Hatchback (6L) 1.4 16V, SEAT Ibiza III Hatchback (6L) 1.2, SEAT Ibiza III Hatchback (6L) 1.9 TDI Joya Racer … View more

The steps may slightly vary depending on the car design.

How to change tie rod end on SEAT IBIZA 3 6L [TUTORIAL AUTODOC]

All the parts you need to replace – Track Rod End for Ibiza III Hatchback (6L) and other SEAT models

Alternative products

Track rod end

SKTE-0280009 STARK Track rod end

4,32 GBP

Shop

SKTE-0280083 STARK Track rod end

4,74 GBP

Shop

SKTE-0280015 STARK Track rod end

5,70 GBP

Shop

SKTE-0280041 STARK Track rod end

8,67 GBP

Shop

SKTE-0280045 STARK Track rod end

8,67 GBP

Shop

SKTE-0280007 STARK Track rod end

9,12 GBP

Shop

9010246 KAMOKA Track rod end

10,14 GBP

Shop

SKTE-0280064 STARK Track rod end

10,16 GBP

Shop

914T0046P RIDEX PLUS Track rod end

10,21 GBP

Shop

TA1796 DELPHI Track rod end

10,47 GBP

Shop

Replacement: track rod end – Seat Ibiza 6L1. List of the tools you'll need:

                      Wire brush

                      WD-40 spray

                      Brake cleaner

                      Copper grease

                      Torque wrench

                      Combination spanner #22

                      Drive socket # 19

                      Wheel impact socket #17

                      Ratchet wrench

                      Tap wrench

                      Vernier caliper

                      Ball joint puller

                      Wheel chock

Buy tools

Replacement: track rod end – Seat Ibiza 6L1. AUTODOC recommends:

Replace tie rod ends in pairs.
The replacement procedure is identical for the right and left tie rod ends.
All work should be done with the engine stopped.

Replacement: track rod end – Seat Ibiza 6L1. Recommended sequence of steps:

Step 1

Secure the wheels with chocks.
Step 2

Loosen the wheel mounting bolts. Use wheel impact socket #17.
Step 3

Raise the front of the car and secure on supports.
Step 4

Unscrew the wheel bolts.

AUTODOC recommends:
Warning! To avoid injury, hold the wheel while unscrewing the fastening bolts. Seat Ibiza 6L1
Step 5

Remove the wheel.
Step 6

Clean the fastener connecting the tie rod end to the steering knuckle. Use a wire brush. Use WD-40 spray.
Step 7

When deinstalling, mark or measure the precise position of the ball joint on the track rod, or count the number of turns in order to prevent misalignment afterward. Use a vernier caliper.
Step 8

Loosen the lock nut securing the tie rod end to the tie rod. Use a combination spanner #22.
Step 9

Unscrew the end fastening nut to the steering knuckle. Use a drive socket #19. Use a tap wrench.
Step 10

Disconnect the tie rod end from the steering knuckle. Use a ball joint puller.
Step 11

Screw the end out of the tie rod.
Step 12

Clean the mounting seats of the tie rod end. Use a wire brush. Use WD-40 spray.
Step 13

Screw on a new tie rod end.

Replacement: track rod end – Seat Ibiza 6L1. Tip from AUTODOC experts:
While installing the steering rod end remember to make the same number of turns or to leave the same length of thread showing as per your measurements
Step 14

Connect the tie rod end to the steering knuckle.
Step 15

When deinstalling, mark or measure the precise position of the ball joint on the track rod, or count the number of turns in order to prevent misalignment afterward. Use a vernier caliper.
Step 16

Screw on the fastening nut that connects the tie rod end to the steering knuckle. Use a drive socket #19. Use a ratchet wrench.
Step 17

Tighten the tie rod end locknut. Use a combination spanner #19. Use a combination spanner #22. Use a torque wrench. Tighten it to 50 nm torque.
Step 18

Tighten the fastening nut connecting the tie rod end to the steering knuckle. Use a drive socket #19. Use a torque wrench. Tighten it to 20 Nm torque.+90°

AUTODOC recommends:
Important! Be sure to use new fasteners.
Step 19

Treat the fastener connecting the tie rod end to the steering knuckle. Use copper grease.
Step 20

Treat the surface where the brake disc contacts the wheel rim. Use copper grease.
Step 21

Clean the brake disk surface. Use a brake cleaner.

AUTODOC recommends:
Replacement: track rod end – Seat Ibiza 6L1. After applying the spray, wait a few minutes.
Step 22

Install the wheel.

AUTODOC recommends:
To avoid injury, hold up the wheel when screwing in the fastening bolts.
Step 23

Screw in the wheel bolts. Use wheel impact socket #17.
Step 24

Lower the car and working in a cross order, tighten the wheel bolts. Use wheel impact socket #17. Use a torque wrench. Tighten it to 120 nm torque.

Replacement: track rod end – Seat Ibiza 6L1. Professionals recommend:
Check and adjust wheel alignment if necessary.
Step 25

Remove the jacks and chocks.
