Tools
Replacement: track rod end – AUDI A4 Avant (8K5, B8). Tools you need:
Wire brush
WD-40 spray
Brake cleaner
Copper grease
Combination spanner #21
Combination spanner #24
Drive socket # 21
Wheel impact socket #17
Torque wrench
Vernier caliper
Wheel chock
Buy tools
Replacement: track rod end – AUDI A4 Avant (8K5, B8). AUTODOC recommends:
  • Replace tie rod ends in pairs.
  • The replacement procedure is identical for the right and left tie rod ends.
  • Please note: all work on the car – AUDI A4 Avant (8K5, B8) – should be done with the engine switched off.
Carry out replacement in the following order:
  1. Step 1
    How to change Track Rod End on Audi A4 B8 Avant 2007 - free PDF and video manuals
    Secure the wheels with chocks.
  2. Step 2
    How to replace AUDI A4 Avant (8K5, B8) 2.0 TDI 2008 Track Rod End - step-by-step manuals and video guides
    Loosen the wheel mounting bolts. Use wheel impact socket #17.
  3. Step 3
    Raise the front of the car and secure on supports.
    Step 4
    Audi A4 B8 Avant 3.0 TDI quattro 2009 Track Rod End replacement: free workshop manuals
    Unscrew the wheel bolts.
    Replacement: track rod end – AUDI A4 Avant (8K5, B8). Tip:
    To avoid injury, hold up the wheel when unscrewing the bolts.
  4. Step 5
    Changing Track Rod End on AUDI A4 Avant (8K5, B8) 2.0 TDI quattro 2010 by yourself
    Remove the wheel.
  5. Step 6
    How to remove AUDI A4 2.0 TDI 2011 Track Rod End - online easy-to-follow instructions
    Clean the fastener connecting the tie rod end to the steering knuckle. Use a wire brush. Use WD-40 spray.
  6. Step 7
    How to replace Track Rod End on AUDI A4 Avant (8K5, B8) 2012: download PDF manuals and video instructions
    Unscrew the end fastening nut to the steering knuckle. Use a combination spanner #21.
  7. Step 8
    How hard is it to do yourself: Track Rod End replacement on Audi A4 B8 Avant 1.8 TFSI 2013 - download illustrated guide
    Clean the lock nut that connects the tie rod to the tie rod end. Use a wire brush. Use WD-40 spray.
  8. Step 9
    Need to know how to renew Track Rod End on AUDI A4 2014? This free workshop manual will help you to do it yourself
    When deinstalling, mark or measure the precise position of the ball joint on the track rod, or count the number of turns in order to prevent misalignment afterward. Use a vernier caliper.
  9. Step 10
    Changing of Track Rod End on Audi A4 B8 Avant 2015 won't be an issue if you follow this illustrated step-by-step guide
    Loosen the lock nut securing the tie rod end to the tie rod. Use a combination spanner #24 (2 pieces).
  10. Step 11
    AUDI A4 2.0 TDI Track Rod End replacement: online guides and video tutorials
    Disconnect the tie rod end from the steering knuckle.
  11. Step 12
    Replacing Track Rod End on Audi A4 B8 Avant 2008 2.0 TDI by yourself
    Screw the end out of the tie rod.
  12. Step 13
    A4 Avant (8K5, B8) 2.0 TDI 2009 Track Rod End DIY replacement workshop manual
    Clean the mounting seats of the tie rod end. Use a wire brush. Use WD-40 spray.
  13. Step 14
    How to change Track Rod End on AUDI A4 Avant (8K5, B8) 2010 - tips and tricks
    Screw on a new tie rod end.
    Replacement: track rod end – AUDI A4 Avant (8K5, B8). AUTODOC experts recommend:
    While installing the steering rod end remember to make the same number of turns or to leave the same length of thread showing as per your measurements.
  14. Step 15
    Step-by-step recommendations for DIY replacement Audi A4 B8 Avant 2011 2.0 TDI Track Rod End
    When deinstalling, mark or measure the precise position of the ball joint on the track rod, or count the number of turns in order to prevent misalignment afterward. Use a vernier caliper.
