When to replace the Poly V-Belt on your CITROËN XSARA
Recommended replacement interval for the part category Serpentine belt : 30000 km
Important!
This replacement procedure can be used for:
CITROËN Xsara Box Body / Hatchback (N3_) 1.8 D, CITROËN Xsara Box Body / Hatchback (N3_) 1.9 D … View more

The steps may slightly vary depending on the car design.

This video shows the replacement procedure of a similar car part on another vehicle

All the parts you need to replace – Poly V-Belt for Xsara Box Body / Hatchback (N3_) and other CITROËN models
How to change Serpentine belt on Xsara 2.0 HDi – step-by-step instructions for straightforward car repair Serpentine belt
How to change V-Ribbed Belt Set on Xsara 2.0 HDi – step-by-step instructions for straightforward car repair V-Ribbed Belt Set
How to change Serpentine belt on Xsara Box Body / Hatchback (N3) – tips for proper car maintenance
Serpentine belt for Xsara Box Body / Hatchback (N3) Diesel (58 hp)
Simple DIY car repair steps – Replacing Serpentine belt on Xsara Box Body / Hatchback (N3)
Serpentine belt for Xsara Box Body / Hatchback (N3) Diesel (88 hp)
Tools
Replacement: serpentine belt – CITROËN XSARA Box Body / Hatchback. List of the tools you'll need:
Wire brush
Torque wrench
Drive socket # 27
HEX bit no.H8
1/4" square drive extension bar
Wheel impact socket #19
Ratchet wrench
Clip removal tool
Phillips screwdriver
Fender cover
Wheel chock
Buy tools
Replacement: serpentine belt – CITROËN XSARA Box Body / Hatchback. Tools you might need:
  • All work should be done with the engine stopped.
Replacement: serpentine belt – CITROËN XSARA Box Body / Hatchback. Use the following procedure:
  1. Step 1
    Open the hood.
    Step 2
    Use a fender protection cover to prevent damaging paintwork and plastic parts of the car.
    Step 3
    Secure the wheels with chocks.
    Step 4
    How to change Poly V-Belt on Xsara 1998 - free PDF and video manuals
    Loosen the wheel mounting bolts. Use wheel impact socket #19.
  2. Step 5
    Raise the car.
    Replacement: serpentine belt – CITROËN XSARA Box Body / Hatchback. AUTODOC recommends:
    If you are using a jack, make sure it rests on a flat surface without any unevenness.Be sure to additionally secure the car with jack stands.
    Step 6
    How to replace CITROËN Xsara Box Body / Hatchback (N3_) 2.0 HDi 1999 Poly V-Belt - step-by-step manuals and video guides
    Unscrew the wheel bolts.
    AUTODOC recommends:
    Warning! To avoid injury, hold the wheel while unscrewing the fastening bolts. CITROËN XSARA Box Body / Hatchback
  3. Step 7
    Xsara 1.9 D 2000 Poly V-Belt replacement: free workshop manuals
    Remove the wheel.
  4. Step 8
    Changing Poly V-Belt on CITROËN Xsara Box Body / Hatchback (N3_) 1.8 D 2001 by yourself
    Unscrew and remove the wheel arch cover fasteners. Use a clip removal tool. Use a Phillips screwdriver.
  5. Step 9
    How to remove CITROËN XSARA 1.5 D 2002 Poly V-Belt - online easy-to-follow instructions
    Remove the wheel arch cover.
  6. Step 10
    How to replace Poly V-Belt on CITROËN Xsara Box Body / Hatchback (N3_) 2003: download PDF manuals and video instructions
    Release the coolant pipe fasteners.
  7. Step 11
    How hard is it to do yourself: Poly V-Belt replacement on Xsara 2.0 HDi 2004 - download illustrated guide
    Clean the tensioner pulley fastener. Use a wire brush.
  8. Step 12
    Need to know how to renew Poly V-Belt on CITROËN XSARA 2005? This free workshop manual will help you to do it yourself
    Loosen the tensioner pulley fastener. Use HEX No.H8. Use a ratchet wrench.
  9. Step 13
    Changing of Poly V-Belt on Xsara 1998 won't be an issue if you follow this illustrated step-by-step guide
    Pull aside the V-ribbed belt tensioner pulley. Use a 1/4" square drive extension bar. Use a ratchet wrench.
  10. Step 14
    CITROËN XSARA 1.4 Poly V-Belt replacement: online guides and video tutorials
    Remove the V-ribbed belt.
    Replacement: serpentine belt – CITROËN XSARA Box Body / Hatchback. Tip from AUTODOC experts:
    Check the condition of the tensioner pulley and idler pulley. Replace them if necessary.
  11. Step 15
    Replacing Poly V-Belt on Xsara 2000 2.0 HDi by yourself
    Install the V-ribbed belt.
    Replacement: serpentine belt – CITROËN XSARA Box Body / Hatchback. Professionals recommend:
    Make sure that the V-ribbed belt fits all pulleys snugly.
  12. Step 16
    Xsara Box Body / Hatchback (N3_) 1.5 D 2001 Poly V-Belt DIY replacement workshop manual
    Tension the belt by turning the tensioner pulley clockwise. Use a 1/4" square drive extension bar. Use a ratchet wrench.
    Replacement: serpentine belt – CITROËN XSARA Box Body / Hatchback. Tip:
    Keep the belt taut until you've tightened the tensioner pulley fastener.
  13. Step 17
    How to change Poly V-Belt on CITROËN Xsara Box Body / Hatchback (N3_) 2002 - tips and tricks
    Tighten the fastener of the serpentine belt tensioner pulley. Use HEX No.H8. Use a torque wrench. Tighten it to 35 Nm torque.
