Change Opel Astra H Saloon 1.3 CDTi (L69) Springs yourself – manuals and video tutorials

How to change rear coil springs on Opel Astra H saloon – replacement guide

downloads: 6
Views: 251
Download your free tutorial and fix OPEL Astra H Saloon (A04) 1.7 CDTi (L69) problems yourself Download for free 1.9 MB Springs for Opel Astra H Saloon Shop now
Leave a comment Open in a new tab
Important!
This replacement procedure can be used for:
OPEL Astra H Saloon (A04) 1.8 (L69), OPEL Astra H Saloon (A04) 1.3 CDTi (L69), OPEL Astra H Saloon (A04) 1.7 CDTi (L69) … View more

The steps may slightly vary depending on the car design.

How to change rear springs on OPEL ASTRA H Saloon [TUTORIAL AUTODOC]

video
Published on: 19/07/2021
4K views
All the parts you need to replace – Springs for Astra H Saloon (A04) and other OPEL models
How to change Coil spring on Opel Astra H Saloon 1.6 (L69) – step-by-step instructions for straightforward car repair Coil spring
How to change Coil spring on Astra H Saloon (A04) – tips for proper car maintenance
Coil spring for Astra H Saloon (A04) Petrol (140 hp)
Simple DIY car repair steps – Replacing Coil spring on Astra H Saloon (A04)
Coil spring for Astra H Saloon (A04) Diesel (90 hp)
Easy tricks to help you to replace Coil spring on Astra H Saloon (A04)
Coil spring for Astra H Saloon (A04) Diesel (101 hp)
Tools
Replacement: coil springs – Opel Astra H saloon. Tools you might need:
Wire brush
WD-40 spray
Brake cleaner
Copper grease
Torque wrench
Drive socket # Е20
Wheel impact socket #17
Ratchet wrench
Tap wrench
Crow bar
Hydraulic transmission jack
Wheel chock
Buy tools
Replacement: coil springs – Opel Astra H saloon. AUTODOC experts recommend:
  • Both coil springs of the rear suspension should be replaced simultaneously.
  • The replacement procedure is identical for the left and right coil springs of the rear suspension.
  • Please note: all work on the car – Opel Astra H saloon – should be done with the engine switched off.
Carry out replacement in the following order:
  1. Step 1
    Secure the wheels with chocks.
    Step 2
    How to change Springs on Opel Astra H Saloon 2007 - free PDF and video manuals
    Loosen the wheel mounting bolts. Use wheel impact socket #17.
  2. Step 3
    How to replace OPEL Astra H Saloon (A04) 1.6 (L69) 2008 Springs - step-by-step manuals and video guides
    Raise the rear of the car and secure on supports.
  3. Step 4
    Opel Astra H Saloon 1.7 CDTi (L69) 2009 Springs replacement: free workshop manuals
    Unscrew the wheel bolts.
    AUTODOC recommends:
    Important! Hold the wheel while unscrewing the fastening bolts. Opel Astra H saloon
  4. Step 5
    Changing Springs on OPEL Astra H Saloon (A04) 1.8 (L69) 2010 by yourself
    Remove the wheel.
  5. Step 6
    How to remove OPEL ASTRA 1.7 CDTI (L69) 2011 Springs - online easy-to-follow instructions
    Clean the shock absorber fasteners. Use a wire brush. Use WD-40 spray.
  6. Step 7
    How to replace Springs on OPEL Astra H Saloon (A04) 2012: download PDF manuals and video instructions
    Support the rear suspension beam. Use a hydraulic transmission jack.
  7. Step 8
    How hard is it to do yourself: Springs replacement on Opel Astra H Saloon 1.6 (L69) 2013 - download illustrated guide
    Unscrew the lower fastener of the shock absorber. Use a drive socket #Е20. Use a tap wrench. Use a ratchet wrench.
  8. Step 9
    Need to know how to renew Springs on OPEL ASTRA 2014? This free workshop manual will help you to do it yourself
    Remove the fastening bolt.
  9. Step 10
    Changing of Springs on Opel Astra H Saloon 2007 won't be an issue if you follow this illustrated step-by-step guide
    Remove the mounting from under the rear axle beam.
    AUTODOC recommends:
    Replacement: coil springs – Opel Astra H saloon. Lower the transmission jack smoothly, without jerks, to avoid damaging components and mechanisms.
  10. Step 11
    OPEL ASTRA 1.3 CDTi (L69) Springs replacement: online guides and video tutorials
    Support the rear suspension beam. Use a hydraulic transmission jack.
  11. Step 12
    Replacing Springs on Opel Astra H Saloon 2009 1.6 (L69) by yourself
    Unscrew the lower fastener of the shock absorber. Use a drive socket #Е20. Use a tap wrench. Use a ratchet wrench.
  12. Step 13
    Astra H Saloon (A04) 1.7 CDTI (L69) 2010 Springs DIY replacement workshop manual
    Remove the fastening bolt.
  13. Step 14
    How to change Springs on OPEL Astra H Saloon (A04) 2011 - tips and tricks
    Remove the mounting from under the rear axle beam.
    AUTODOC recommends:
    Opel Astra H saloon – Do not lower the transmission jack sharply to avoid damaging components and mechanisms of the car.
  14. Step 15
    Step-by-step recommendations for DIY replacement Opel Astra H Saloon 2012 1.7 CDTI (L69) Springs
    Pull down the rear suspension beam. Use a crowbar.
  15. Step 16
    DIY replacement of Springs on OPEL Astra H Saloon (A04) 1.3 CDTi (L69) 2013 is not an issue anymore with our step-by-step tutorial
    Remove the spring.
    Replacement: coil springs – Opel Astra H saloon. Tip from AUTODOC:
    Inspect the rubber mounts of the suspension spring. Replace if necessary.
  16. Step 17
    How to change Springs on Opel Astra H Saloon 2007 - free PDF and video manuals
    Clean the coil spring mounting seats. Use a wire brush. Use WD-40 spray.
  17. Step 18
    How to replace OPEL Astra H Saloon (A04) 1.6 (L69) 2008 Springs - step-by-step manuals and video guides
    Pull down the rear suspension beam. Use a crowbar.
  18. Step 19
    Opel Astra H Saloon 1.7 CDTi (L69) 2009 Springs replacement: free workshop manuals
    Install the coil spring together with the rubber mounts into the mounting seats.
  19. Step 20
    Changing Springs on OPEL Astra H Saloon (A04) 1.8 (L69) 2010 by yourself
    Support the rear suspension beam. Use a hydraulic transmission jack.
  20. Step 21
    How to remove OPEL ASTRA 1.7 CDTI (L69) 2011 Springs - online easy-to-follow instructions
    Install the fastening bolt.
