Important!
This replacement procedure can be used for:
FIAT PUNTO (188) 1.2 16V 80 (188.233, .235, .253, .255, .333, .353, .639,..., FIAT PUNTO (188) 1.9 JTD 80 (188.237, .257, .337, .357), FIAT PUNTO (188) 1.9 DS 60 (188.031, .051, .231, .251), FIAT PUNTO (188) 1.9 JTD View more

The steps may slightly vary depending on the car design.

How to change rear springs / rear coil springs on FIAT PUNTO 2 (188) [TUTORIAL AUTODOC]

video
Tools
Replacement: coil springs – Fiat Punto 188. List of the tools you'll need:
Wire brush
WD-40 spray
Copper grease
Drive socket # 18
Wheel impact socket #19
Torque wrench
Hydraulic transmission jack
Wheel chock
Replacement: coil springs – Fiat Punto 188. AUTODOC experts recommend:
  • Both coil springs of the rear suspension should be replaced simultaneously.
  • The replacement procedure is identical for the left and right coil springs of the rear suspension.
  • All work should be done with the engine stopped.
Replacement: coil springs – Fiat Punto 188. Recommended sequence of steps:
  1. Step 1
    How to change Springs on Fiat Punto Mk2 1999 - free PDF and video manuals
    Secure the wheels with chocks.
  2. Step 2
    How to replace FIAT PUNTO (188) 1.2 60 2000 Springs - step-by-step manuals and video guides
    Loosen the wheel mounting bolts. Use wheel impact socket #19.
  3. Step 3
    Fiat Punto Mk2 1.2 16V 80 (188.233, .235, .253, .255, .333, .353, .639,... 2001 Springs replacement: free workshop manuals
    Raise the rear of the car and secure on supports.
  4. Step 4
    Changing Springs on FIAT PUNTO (188) 1.9 JTD 80 2002 by yourself
    Unscrew the wheel bolts.
    AUTODOC recommends:
    Important! Hold the wheel while unscrewing the fastening bolts. Fiat Punto 188
  5. Step 5
    How to remove FIAT PUNTO 1.9 JTD 2003 Springs - online easy-to-follow instructions
    Remove the wheel.
  6. Step 6
    How to replace Springs on FIAT PUNTO (188) 2004: download PDF manuals and video instructions
    Support the rear suspension beam. Use a hydraulic transmission jack.
  7. Step 7
    Clean the shock absorber fasteners. Use a wire brush. Use WD-40 spray.
    Step 8
    How hard is it to do yourself: Springs replacement on Fiat Punto Mk2 1.4 2005 - download illustrated guide
    Unscrew the lower fastener of the shock absorber. Use a drive socket #18.
  8. Step 9
    Need to know how to renew Springs on FIAT PUNTO 2006? This free workshop manual will help you to do it yourself
    Remove the fastening bolt.
  9. Step 10
    Changing of Springs on Fiat Punto Mk2 2007 won't be an issue if you follow this illustrated step-by-step guide
    Remove the mounting from under the rear axle beam.
    Replacement: coil springs – Fiat Punto 188. Professionals recommend:
    Lower the hydraulic transmission jack smoothly, without jerks, to avoid damaging assemblies and mechanisms.
  10. Step 11
    FIAT PUNTO 1.9 DS 60 Springs replacement: online guides and video tutorials
    Support the rear suspension beam. Use a hydraulic transmission jack.
  11. Step 12
    Replacing Springs on Fiat Punto Mk2 2009 1.2 60 by yourself
    Unscrew the lower fastener of the shock absorber. Use a drive socket #18.
  12. Step 13
    PUNTO (188) 1.9 JTD 2010 Springs DIY replacement workshop manual
    Remove the mounting from under the rear axle beam.
    AUTODOC recommends:
    Replacement: coil springs – Fiat Punto 188. Lower the transmission jack smoothly, without jerks, to avoid damaging components and mechanisms.
  13. Step 14
    How to change Springs on FIAT PUNTO (188) 2011 - tips and tricks
    Take out the spring.
  14. Step 15
    Step-by-step recommendations for DIY replacement Fiat Punto Mk2 2012 1.9 JTD Springs
    Remove the rubber spring spacer.
  15. Step 16
    Install the rubber spacer on the new coil spring.
    Step 17
    DIY replacement of Springs on FIAT PUNTO (188) 1.3 JTD 16V 1999 is not an issue anymore with our step-by-step tutorial
    Clean the coil spring mounting seats. Use a wire brush. Use WD-40 spray.
  16. Step 18
    How to change Springs on Fiat Punto Mk2 1999 - free PDF and video manuals
    Install the spring.
    Replacement: coil springs – Fiat Punto 188. AUTODOC experts recommend:
    Make sure that the coil spring is correctly positioned in its mounting seats.
  17. Step 19
    How to replace FIAT PUNTO (188) 1.2 60 2000 Springs - step-by-step manuals and video guides
    Support the rear suspension beam. Use a hydraulic transmission jack.
