Recommended replacement interval for the part category Brake disc : 50000 km

Important!

This replacement procedure can be used for:
VW Touareg (7LA, 7L6, 7L7) 3.2 V6, VW Touareg (7LA, 7L6, 7L7) 5.0 V10 TDI, VW Touareg (7LA, 7L6, 7L7) 4.2 V8, VW Touareg (7LA, 7L6, 7L7) 2.5 R5 TDI, VW Touareg (7LA, 7L6, 7L7) 3.2 V6, VW Touareg (7LA, 7L6, 7L7) 3.0 V6 TDI, VW Touareg (7LA, 7L6, 7L7) 6.0 W12, VW Touareg (7LA, 7L6, 7L7) 3.6 V6 FSI, VW Touareg (7LA, 7L6, 7L7) 4.2 V8 FSI, VW Touareg (7LA, 7L6, 7L7) 5.0 R50 TDI, VW Touareg (7LA, 7L6, 7L7) 3.0 V6 TDI, VW Touareg (7LA, 7L6, 7L7) 2.5 R5 TDI, VW Touareg (7LA, 7L6, 7L7) 3.0 TDI … View more

The steps may slightly vary depending on the car design.

This video shows the replacement procedure of a similar car part on another vehicle

All the parts you need to replace – Brake Discs for Touareg (7LA, 7L6, 7L7) and other VW models

Alternative products

Brake disc

82B0189 RIDEX Brake disc

33,60 GBP

Shop

SKBD-0020193 STARK Brake disc

38,24 GBP

Shop

0 986 479 211 BOSCH Brake disc

45,12 GBP

Shop

BG9891 DELPHI Brake disc

45,14 GBP

Shop

BDC5424 QUINTON HAZELL Brake disc

47,85 GBP

Shop

V2005V LPR Brake disc

52,88 GBP

Shop

C3W037ABE ABE Brake disc

52,93 GBP

Shop

186756 VALEO Brake disc

57,59 GBP

Shop

24.0130-0114.1 ATE Brake disc

62,18 GBP

Shop

1031118 KAMOKA Brake disc

92,81 GBP

Shop

Replacement: brake discs – VW TOUAREG (7LA, 7L6, 7L7). Tools you might need:

                      Wire brush

                      Nylon cleaning brush

                      WD-40 spray

                      Brake cleaner

                      Copper grease

                      Torque wrench

                      Drive socket # 21

                      HEX bit No.H7

                      XZN bit #10

                      Wheel impact socket #19

                      Ratchet wrench

                      Impact screwdriver

                      Tap wrench

                      Brake caliper wind back tool

                      Crow bar

                      Wheel chock

Buy tools

Replacement: brake discs – VW TOUAREG (7LA, 7L6, 7L7). AUTODOC experts recommend:

Replace the brake disks on the car VW TOUAREG (7LA, 7L6, 7L7) in complete set for each axis. Regardless of the state of components. This will ensure even braking.
The replacement procedure is identical for both brake disks on the same axle.
When changing the brake discs, always replace the brake pads.
Please note: all work on the car – VW TOUAREG (7LA, 7L6, 7L7) – should be done with the engine switched off.

Carry out replacement in the following order:

Step 1

Open the bonnet. Unscrew the brake fluid reservoir cap.

Step 2

Secure the wheels with chocks.

Step 3

Loosen the wheel mounting bolts. Use wheel impact socket #19.
Step 4

Raise the front of the car and secure on supports.

Step 5

Unscrew the wheel bolts.

AUTODOC recommends:
Warning! To avoid injury, hold the wheel while unscrewing the fastening bolts. VW TOUAREG (7LA, 7L6, 7L7)
Step 6

Remove the wheel.
Step 7

Remove the dust boot caps of the brake caliper guide pins. Use a crowbar.
Step 8

Unscrew the brake caliper fastening. Use HEX No.H7. Use a ratchet wrench.
Step 9

Spread the brake pads. Use a crowbar.
Step 10

Detach the brake caliper retaining spring. Use a crowbar.
Step 11

Remove the brake caliper.

Replacement: brake discs – VW TOUAREG (7LA, 7L6, 7L7). Professionals recommend:
Tie the caliper to the suspension or to the body with a wire without disconnecting from the brake hose to prevent depressurization of the brake system.Make sure that the brake caliper is not hanging on the brake hose.Don't press the brake pedal after the brake caliper has been removed. As a result, the piston can fall out from the brake cylinder, and brake fluid leakage and depressurization of the system may occur. Check the brake caliper bracket, brake caliper guide pins and boots. Clean them. Replace, if necessary.
Step 12

Remove the brake pads.
Step 13

Clean the brake caliper bracket fasteners. Use a wire brush. Use WD-40 spray.
Step 14

Unscrew the caliper bracket fastening. Use a drive socket #21. Use a ratchet wrench. Use a tap wrench.
Step 15

Remove the caliper bracket.
Step 16

Clean the brake disc fastener. Use a wire brush. Use WD-40 spray.
Step 17

Unscrew the brake disc fastening. Use XZN #10. Use an impact screwdriver.
Step 18

Remove the brake disc.
Step 19

Clean the hub. Use a wire brush. Treat the contacting surface. Use copper grease.
Step 20

Install the brake disc.
Step 21

Screw in the brake disc fastener. Use XZN #10. Use a ratchet wrench.
Step 22

Clean the brake caliper bracket from dirt and dust. Use a wire brush. Use a brake cleaner.

AUTODOC recommends:
Replacement: brake discs – VW TOUAREG (7LA, 7L6, 7L7). After applying the spray, wait a few minutes.
Step 23

Install the brake caliper bracket.
Step 24

Tighten the brake caliper bracket. Use a drive socket #21. Use a torque wrench. Tighten it to 180 Nm torque.+45°

AUTODOC recommends:
Important! Be sure to use new fasteners.
Step 25

Tighten the brake disc fastening. Use XZN #10. Use a torque wrench. Tighten it to 17 Nm torque.
Step 26

Treat the brake caliper piston. Use a nylon cleaning brush. Use a brake cleaner.

AUTODOC recommends:
After applying the spray, wait a few minutes.
Step 27

Press in the brake caliper piston. Use brake caliper wind back tool.
Step 28

Install the brake pads.
Step 29

Install the brake caliper and fix it. Use HEX No.H7. Use a torque wrench. Tighten it to 30 nm torque.
Step 30

Install the dust boot caps of the brake caliper guide pins.
Step 31

Install the brake caliper retaining spring.
Step 32

Treat the surface where the brake disc contacts the wheel rim. Use copper grease.
Step 33

Clean the brake disk surface. Use a brake cleaner.

AUTODOC recommends:
Replacement: brake discs – VW TOUAREG (7LA, 7L6, 7L7). After applying the spray, wait a few minutes.
Step 34

Install the wheel.

AUTODOC recommends:
To avoid injury, hold up the wheel when screwing in the fastening bolts.
Step 35

Screw in the wheel bolts. Use wheel impact socket #19.
Step 36

Lower the car and working in a cross order, tighten the wheel bolts. Use wheel impact socket #19. Use a torque wrench. Tighten it to 180 Nm torque.
Step 37

Remove the jacks and chocks.

Replacement: brake discs – VW TOUAREG (7LA, 7L6, 7L7). AUTODOC recommends:
Check the brake fluid level in the expansion tank and refill if necessary.Without starting the engine, press the brake pedal several times until you feel significant resistance.
Step 38

Tighten the brake fluid reservoir cap. Close the hood.
