When to replace the Oil Filter on your TOYOTA RAV4
Recommended replacement interval for the part category Oil filter : 1 year / 15000 km
Important!
This replacement procedure can be used for:
TOYOTA RAV 4 III (ACA3_, ACE_, ALA3_, GSA3_, ZSA3_) 2.4 4WD (ACA31, ACA33), TOYOTA RAV 4 III (ACA3_, ACE_, ALA3_, GSA3_, ZSA3_) 2.0 4WD (ACA30_), TOYOTA RAV 4 III (ACA3_, ACE_, ALA3_, GSA3_, ZSA3_) 2.4 (ACA36, ACA38) View more

The steps may slightly vary depending on the car design.

How to change oil filter and engine oil on TOYOTA RAV 4 3 (XA30) [TUTORIAL AUTODOC]

video
Tools
Replacement: engine oil and filter – Toyota RAV4 III. Tools you need:
Wire brush
All-purpose cleaning spray
Drive socket # 12
Drive socket # 15
Oil filter cup socket 76-14F
Ratchet wrench
Torque wrench
Oil drain pan
Funnel
Fender cover
Replacement: engine oil and filter – Toyota RAV4 III. AUTODOC experts recommend:
  • Replace the oil filter every time when changing motor oil.
  • Wear gloves to prevent contact with hot liquid.
  • Please note: all work on the car – Toyota RAV4 III – should be done with the engine switched off.
Carry out replacement in the following order:
  1. Step 1
    How to change Oil Filter on Toyota RAV4 III 2005 - free PDF and video manuals
    Open the hood.
  2. Step 2
    How to replace TOYOTA RAV 4 III (ACA3_, ACE_, ALA3_, GSA3_, ZSA3_) 2.2 D 4WD (ALA30_) 2006 Oil Filter - step-by-step manuals and video guides
    Use a fender protection cover to prevent damaging paintwork and plastic parts of the car.
  3. Step 3
    Toyota RAV4 III 2.0 4WD (ACA30_) 2007 Oil Filter replacement: free workshop manuals
    Unscrew the oil filler plug.
  4. Step 4
    Changing Oil Filter on TOYOTA RAV 4 III (ACA3_, ACE_, ALA3_, GSA3_, ZSA3_) 2.0 4WD (ZSA30_) 2008 by yourself
    Lift the car using a jack or place it over an inspection pit.
    Replacement: engine oil and filter – Toyota RAV4 III. Tip from AUTODOC:
    The vehicle must be on even keel, and if it is at an angle, the drain plug must be at the lowest point.All work should be done with the engine stopped.
  5. Step 5
    How to remove TOYOTA RAV4 2.0 (ZSA35_) 2009 Oil Filter - online easy-to-follow instructions
    Undo the fasteners of the oil pan lower cover. Use a drive socket #12.
  6. Step 6
    How to replace Oil Filter on TOYOTA RAV 4 III (ACA3_, ACE_, ALA3_, GSA3_, ZSA3_) 2010: download PDF manuals and video instructions
    Remove the oil pan cover.
  7. Step 7
    How hard is it to do yourself: Oil Filter replacement on Toyota RAV4 III 2.0 4WD (ZSA30) 2011 - download illustrated guide
    Clean the cap of the oil filler neck. Use a wire brush. Use all-purpose cleaning spray.
  8. Step 8
    Need to know how to renew Oil Filter on TOYOTA RAV4 2012? This free workshop manual will help you to do it yourself
    Put a waste oil container with at least 5 l capacity under the drainage hole.
  9. Step 9
    Changing of Oil Filter on Toyota RAV4 III 2013 won't be an issue if you follow this illustrated step-by-step guide
    Unscrew the drain plug. Use a drive socket #15. Use a ratchet wrench.
  10. Step 10
    TOYOTA RAV4 2.2 D 4WD (ALA30_) Oil Filter replacement: online guides and video tutorials
    Drain the used oil.
    Replacement: engine oil and filter – Toyota RAV4 III. AUTODOC experts recommend:
    Caution! The oil may be hot.Wait until the oil has completely drained from the drainage hole.
  11. Step 11
    Prepare a container for the old oil filter.
    Step 12
    Replacing Oil Filter on Toyota RAV4 III 2006 2.2 D 4WD (ALA30_) by yourself
    Unscrew the oil filter. Use the 76-14F socket. Use a ratchet wrench.
  12. Step 13
    Put the old oil filter in the container.
    Replacement: engine oil and filter – Toyota RAV4 III. AUTODOC recommends:
    Move up the container. The oil starts to drain out of the drainage hole immediately after you have removed the oil filter.
    Step 14
    RAV 4 III (ACA3_, ACE_, ALA3_, GSA3_, ZSA3_) 2.0 (ZSA35_) 2007 Oil Filter DIY replacement workshop manual
    Clean the oil filter seat.
  13. Step 15
    How to change Oil Filter on TOYOTA RAV 4 III (ACA3_, ACE_, ALA3_, GSA3_, ZSA3_) 2008 - tips and tricks
    Lubricate the rubber seal of the new filter with a little amount of fresh oil.
  14. Step 16
    Step-by-step recommendations for DIY replacement Toyota RAV4 III 2009 2.0 (ZSA35_) Oil Filter
    Screw the new filter into its place. Use the 76-14F socket. Use a torque wrench. Tighten it to 17 Nm torque.
  15. Step 17
    DIY replacement of Oil Filter on TOYOTA RAV 4 III (ACA3_, ACE_, ALA3_, GSA3_, ZSA3_) 2.2 D (ALA35_) 2010 is not an issue anymore with our step-by-step tutorial
    Clean the area of the oil pan drainage hole.
