Important!
This replacement procedure can be used for:
OPEL Astra G CC (T98) 1.2 16V (F08, F48), OPEL Astra G CC (T98) 1.6 (F08, F48), OPEL Astra G CC (T98) 1.6 16V (F08, F48), OPEL Astra G CC (T98) 1.8 16V (F08, F48), OPEL Astra G CC (T98) 2.0 16V (F08, F48), OPEL Astra G CC (T98) 1.7 TD (F08, F48), OPEL Astra G CC (T98) 2.0 DI (F08, F48), OPEL Astra G CC (T98) 2.2 DTI (F08, F48), OPEL Astra G CC (T98) 1.4 16V (F08, F48), OPEL Astra G CC (T98) 2.0 16V OPC (F08, F48), OPEL Astra G CC (T98) 2.0 DTI 16V (F08, F48), OPEL Astra G CC (T98) 1.7 DTI 16V (F08, F48), OPEL Astra G CC (T98) 1.2 16V (F08, F48), OPEL Astra G CC (T98) 1.6 (F08, F48), OPEL Astra G CC (T98) 1.8 16V (F08, F48), OPEL Astra G CC (T98) 2.2 16V (F08, F48), OPEL Astra G CC (T98) 2.0 OPC (F08, F48), OPEL Astra G CC (T98) 2.2 DTI (F08, F48), OPEL Astra G CC (T98) 1.6 (F08, F48), OPEL Astra G CC (T98) 2.0 OPC (F08, F48), OPEL Astra G CC (T98) 1.8 (F08, F48), OPEL Astra G CC (T98) 1.4 (F08, F48), OPEL Astra G CC (T98) 1.6 LPG (F08, F48), OPEL Astra G CC (T98) 1.6 LPG (F08, F48), OPEL Astra G CC (T98) 1.4 LPG (F08, F48) View more

The steps may slightly vary depending on the car design.

How to change tie rod end / track rod end on OPEL ASTRA G TUTORIAL | AUTODOC

video
All the parts you need to replace – Track Rod End for Astra G CC (T98) and other OPEL models
How to change Track rod end on Opel Astra g f48 1.6 16V (F08, F48) – step-by-step instructions for straightforward car repair
Track rod end
How to change Rod Assembly on Opel Astra g f48 1.6 16V (F08, F48) – step-by-step instructions for straightforward car repair
Rod Assembly
How to change Repair Kit, tie rod on Opel Astra g f48 1.6 16V (F08, F48) – step-by-step instructions for straightforward car repair
Repair Kit, tie rod
How to change Mounting Kit, tie rod end on Opel Astra g f48 1.6 16V (F08, F48) – step-by-step instructions for straightforward car repair
Mounting Kit, tie rod end
Tools
Replacement: track rod end – Opel Astra G F48. Tools you might need:
Wire brush
WD-40 spray
Brake cleaner
High-temperature ceramic grease
Copper grease
Combination spanner #22
Drive socket # 19
Wheel impact socket #17
Ratchet wrench
Torque wrench
Vernier caliper
Ball joint puller
Wheel chock
Replacement: track rod end – Opel Astra G F48. AUTODOC recommends:
  • Replace tie rod ends in pairs.
  • The replacement procedure is identical for the right and left tie rod ends.
  • All work should be done with the engine stopped.
Replacement: track rod end – Opel Astra G F48. Recommended sequence of steps:
  1. Step 1
    How to change Track Rod End on Opel Astra g f48 1998 - free PDF and video manuals
    Secure the wheels with chocks.
  2. Step 2
    How to replace OPEL Astra G CC (T98) 1.6 16V (F08, F48) 1999 Track Rod End - step-by-step manuals and video guides
    Loosen the wheel mounting bolts.Use wheel impact socket #17.
  3. Step 3
    Opel Astra g f48 1.6 (F08, F48) 2000 Track Rod End replacement: free workshop manuals
    Raise the front of the car and secure on supports.
  4. Step 4
    Changing Track Rod End on OPEL Astra G CC (T98) 2.0 DTI 16V (F08, F48) 2001 by yourself
    Unscrew the wheel bolts.
    AUTODOC recommends:
    Important! Hold the wheel while unscrewing the fastening bolts. Opel Astra G F48
  5. Step 5
    How to remove OPEL ASTRA 1.7 DTI 16V (F08, F48) 2002 Track Rod End - online easy-to-follow instructions
    Remove the wheel.
  6. Step 6
    How to replace Track Rod End on OPEL Astra G CC (T98) 2003: download PDF manuals and video instructions
    When deinstalling, mark or measure the precise position of the ball joint on the track rod, or count the number of turns in order to prevent misalignment afterward.Use a vernier caliper.
  7. Step 7
    Clean the fastener connecting the tie rod end to the steering knuckle. Use a wire brush.Use WD-40 spray.
    Step 8
    How hard is it to do yourself: Track Rod End replacement on Opel Astra g f48 2.0 DI (F08, F48) 2004 - download illustrated guide
    Unscrew the end fastening nut to the steering knuckle.Use a drive socket #19.Use a ratchet wrench.
  8. Step 9
    Need to know how to renew Track Rod End on OPEL ASTRA 2005? This free workshop manual will help you to do it yourself
    Disconnect the tie rod end from the steering knuckle.Use a ball joint puller.
  9. Step 10
    Clean the lock nut that connects the tie rod to the tie rod end.Use a wire brush.Use WD-40 spray.
    Step 11
    Changing of Track Rod End on Opel Astra g f48 2006 won't be an issue if you follow this illustrated step-by-step guide
    Loosen the lock nut securing the tie rod end to the tie rod.Use a combination spanner #22.
  10. Step 12
    OPEL ASTRA 1.6 16V (F08, F48) Track Rod End replacement: online guides and video tutorials
    Screw the end out of the tie rod.
  11. Step 13
    Replacing Track Rod End on Opel Astra g f48 2008 1.6 16V (F08, F48) by yourself
    Clean the mounting seats of the tie rod end.Use a wire brush.Use WD-40 spray.
  12. Step 14
    Astra G CC (T98) 1.7 DTI 16V (F08, F48) 2009 Track Rod End DIY replacement workshop manual
    Screw on a new tie rod end.
    Replacement: track rod end – Opel Astra G F48. AUTODOC experts recommend:
    While installing the steering rod end remember to make the same number of turns or to leave the same length of thread showing as per your measurements.
