Important!
This replacement procedure can be used for:
OPEL ZAFIRA B (A05) 1.7 CDTI (M75), OPEL ZAFIRA B (A05) 1.6 CNG Turbo (M75), OPEL ZAFIRA B (A05) 1.7 CDTI (M75), OPEL ZAFIRA B (A05) 1.6 (M75), OPEL ZAFIRA B (A05) 2.0 (M75), OPEL ZAFIRA B (A05) 2.2 (M75), OPEL ZAFIRA B (A05) 1.9 CDTI (M75), OPEL ZAFIRA B (A05) 1.9 CDTI (M75), OPEL ZAFIRA B (A05) 1.9 CDTI (M75), OPEL ZAFIRA B (A05) 2.0 (M75), OPEL ZAFIRA B (A05) 1.6 CNG (M75), OPEL ZAFIRA B (A05) 1.6 (M75) View more

The steps may slightly vary depending on the car design.

How to change rear shock absorber on OPEL ZAFIRA-B 2 (A05) [TUTORIAL AUTODOC]

video
All the parts you need to replace – Shock Absorber for ZAFIRA B (A05) and other OPEL models
How to change Shock absorber on Opel Zafira B 1.9 CDTI (M75) – step-by-step instructions for straightforward car repair
Shock absorber
How to change Suspension Strut on Opel Zafira B 1.9 CDTI (M75) – step-by-step instructions for straightforward car repair
Suspension Strut
Tools
Replacement: shock absorbers – Opel Zafira B A05. Tools you need:
Wire brush
WD-40 spray
Brake cleaner
Copper grease
Drive socket # E18
Drive socket # E20
Wheel impact socket #17
Torque wrench
Tap wrench
Hydraulic transmission jack
Wheel chock
Replacement: shock absorbers – Opel Zafira B A05. Tip from AUTODOC:
  • Both shock absorbers of the rear suspension should be replaced simultaneously.
  • The replacement procedure is identical for the left and right shock absorbers of the rear suspension.
  • Warning! Shut down the engine before starting any work – Opel Zafira B A05.
Carry out replacement in the following order:
  1. Step 1
    How to change Shock Absorber on Opel Zafira B 2005 - free PDF and video manuals
    Secure the wheels with chocks.
  2. Step 2
    How to replace OPEL ZAFIRA B (A05) 1.9 CDTI (M75) 2006 Shock Absorber - step-by-step manuals and video guides
    Loosen the wheel mounting bolts. Use wheel impact socket #17.
  3. Step 3
    Opel Zafira B 1.8 (M75) 2007 Shock Absorber replacement: free workshop manuals
    Raise the rear of the car and secure on supports.
  4. Step 4
    Changing Shock Absorber on OPEL ZAFIRA B (A05) 1.6 (M75) 2008 by yourself
    Unscrew the wheel bolts.
    Replacement: shock absorbers – Opel Zafira B A05. AUTODOC experts recommend:
    To avoid injury, hold up the wheel when unscrewing the bolts.
  5. Step 5
    How to remove OPEL ZAFIRA 1.6 CNG (M75) 2009 Shock Absorber - online easy-to-follow instructions
    Remove the wheel.
  6. Step 6
    How to replace Shock Absorber on OPEL ZAFIRA B (A05) 2010: download PDF manuals and video instructions
    Support the rear suspension beam. Use a hydraulic transmission jack.
  7. Step 7
    How hard is it to do yourself: Shock Absorber replacement on Opel Zafira B 1.9 CDTI (M75) 2011 - download illustrated guide
    Clean the shock absorber fasteners. Use a wire brush. Use WD-40 spray.
  8. Step 8
    Need to know how to renew Shock Absorber on OPEL ZAFIRA 2012? This free workshop manual will help you to do it yourself
    Unscrew the lower fastener of the shock absorber. Use a drive socket #E20. Use a tap wrench.
  9. Step 9
    Changing of Shock Absorber on Opel Zafira B 2013 won't be an issue if you follow this illustrated step-by-step guide
    Remove the fastening bolt.
  10. Step 10
    OPEL ZAFIRA 1.7 CDTI (M75) Shock Absorber replacement: online guides and video tutorials
    Unscrew the upper fastener of the shock absorber. Use a drive socket #E18. Use a tap wrench.
  11. Step 11
    Replacing Shock Absorber on Opel Zafira B 2015 1.9 CDTI (M75) by yourself
    Remove the fastening bolt.
    AUTODOC recommends:
    Important! Hold the shock absorber while unscrewing the fastening bolts. Opel Zafira B A05
  12. Step 12
    ZAFIRA B (A05) 1.6 CNG (M75) 2005 Shock Absorber DIY replacement workshop manual
    Remove the shock absorber.
  13. Step 13
    How to change Shock Absorber on OPEL ZAFIRA B (A05) 2006 - tips and tricks
    Clean the shock absorber mounting seats. Use a wire brush. Use WD-40 spray.
    Replacement: shock absorbers – Opel Zafira B A05. Tip:
    Before installing a new shock absorber you should pump it manually 3-5 times.
  14. Step 14
    Step-by-step recommendations for DIY replacement Opel Zafira B 2007 1.6 CNG (M75) Shock Absorber
    Place the shock absorber in the wheel arch and secure it.
    Replacement: shock absorbers – Opel Zafira B A05. Tip from AUTODOC experts:
    To avoid injury, hold the shock absorber cautiously tight when screwing in the fastening bolts.
  15. Step 15
    Install the fastening bolt.
    Step 16
    DIY replacement of Shock Absorber on OPEL ZAFIRA B (A05) 1.7 CDTI (M75) 2008 is not an issue anymore with our step-by-step tutorial
    Screw the upper fastener of the shock absorber. Use a drive socket #E18.
  16. Step 17
    How to change Shock Absorber on Opel Zafira B 2005 - free PDF and video manuals
    Install the fastening bolt.
