How to change ignition coil on Seat Ibiza 6L1 – replacement guide
downloads:
19
Views:
393
0
Users voted – 0
Important!
This replacement procedure can be used for:
SEAT Ibiza III Hatchback (6L) 1.2,
SEAT Ibiza III Hatchback (6L) 1.4 16V,
SEAT Ibiza III Hatchback (6L) 1.2 12V,
SEAT Ibiza III Hatchback (6L) 1.6 16V,
SEAT Ibiza III Hatchback (6L) 1.4 16V
…
View more
The steps may slightly vary depending on the car design.
How to change ignition coil on SEAT IBIZA 3 6L [TUTORIAL AUTODOC]
All the parts you need to replace – Ignition Coil for Ibiza III Hatchback (6L) and other SEAT models
Use a fender protection cover to prevent damaging paintwork and plastic parts of the car.
Step 3
On the right side, detach the PCV valve hose from the engine cover.
Step 4
Remove the engine cover assembled with the air filter housing.
Replacement: ignition coil – Seat Ibiza 6L1. Tip:
Do not apply excessive force when removing the part. Otherwise you may damage it.
Step 5
Cover the throttle body with a microfibre towel to prevent dust and dirt from getting into the system.
Step 6
Take out the ignition coil from the spark plug well. Use a crowbar.
AUTODOC recommends:
Remember the sequence of steps for ignition coil demounting.
Step 7
Unplug the connectors from the ignition coils.
Step 8
Treat the ignition coil connector with electronic spray. The spray will protect the electrical contacts from corrosion, oxidation, and will reduce the contact resistance.
Step 9
Plug in the connectors of the ignition coils.
Step 10
Install the ignition coils to the spark plug wells. Make sure you hear a click indicating that it is locked in place.
Remove the microfibre towel from the throttle body.
Step 12
Install the engine cover and secure it.
AUTODOC recommends:
Caution! Do not use excessive force during installation. This may damage the fasteners of the car. Seat Ibiza 6L1Make sure the engine cover is properly seated. It should not be displaced with respect to the guiding fasteners and the throttle body air intake hose.
Step 13
On the right side, attach the PCV valve hose to the engine cover.
Step 14
Remove the fender protection cover.
Step 15
Close the hood.
Step 16
Run the engine for a few minutes. This is necessary in order to make sure that the component operates properly.
Step 17
Shut off the engine.
