Important!
This replacement procedure can be used for:
BMW 1 Coupe (E82) M, BMW 1 Coupe (E82) 118 d, BMW 1 Coupe (E82) 135 i, BMW 1 Coupe (E82) 120 d, BMW 1 Coupe (E82) 123 d, BMW 1 Coupe (E82) 125 i, BMW 1 Coupe (E82) 120 d, BMW 1 Coupe (E82) 120 i, BMW 1 Coupe (E82) 118 d, BMW 1 Coupe (E82) 128 i, BMW 1 Coupe (E82) 120 i, BMW 1 Coupe (E82) 120 d, BMW 1 Coupe (E82) 135 i View more

The steps may slightly vary depending on the car design.

How to change front strut mount on BMW 1 Series E82 [TUTORIAL AUTODOC]

video
Tools
Replacement: strut mount – BMW E82. Tools you'll need:
Wire brush
WD-40 spray
Brake cleaner
Copper grease
Combination spanner #13
Combination spanner #18
HEX bit no.H6.
Drive socket # 13
Drive socket # 15
Drive socket # 18
Drive socket # 21
Wheel impact socket #17
Shock absorber socket
Ratchet wrench
Torque wrench
Tap wrench
Crow bar
Hydraulic strut spring compressor
Hydraulic transmission jack
Fender cover
Wheel chock
Replacement: strut mount – BMW E82. AUTODOC experts recommend:
  • The replacement procedure is identical for the mounts of the left and right shock struts of the front suspension.
  • All mounts of the front shock struts should be replaced simultaneously.
  • All work should be done with the engine stopped.
Replacement: strut mount – BMW E82. Recommended sequence of steps:
  1. Step 1
    How to change Strut Mount on BMW E82 2006 - free PDF and video manuals
    Open the bonnet.
  2. Step 2
    How to replace BMW 1 Coupe (E82) 120 d 2007 Strut Mount - step-by-step manuals and video guides
    Use a fender protection cover to prevent damaging paintwork and plastic parts of the car.
  3. Step 3
    BMW E82 123 d 2008 Strut Mount replacement: free workshop manuals
    Clean the fasteners of the shock strut upper mount. Use a wire brush. Use WD-40 spray.
  4. Step 4
    Changing Strut Mount on BMW 1 Coupe (E82) 118d 2.0 2009 by yourself
    Loosen the upper fastener of the shock strut mount. Use a combination spanner #13.
  5. Step 5
    How to remove BMW 1 SERIES 125 i 2010 Strut Mount - online easy-to-follow instructions
    Secure the wheels with chocks.
  6. Step 6
    How to replace Strut Mount on BMW 1 Coupe (E82) 2011: download PDF manuals and video instructions
    Loosen the wheel mounting bolts. Use wheel impact socket #17.
  7. Step 7
    How hard is it to do yourself: Strut Mount replacement on BMW E82 120i 2.0 2012 - download illustrated guide
    Raise the front of the car and secure on supports.
  8. Step 8
    Need to know how to renew Strut Mount on BMW 1 SERIES 2013? This free workshop manual will help you to do it yourself
    Unscrew the wheel bolts.
    Replacement: strut mount – BMW E82. Tip:
    To avoid injury, hold up the wheel when unscrewing the bolts.
  9. Step 9
    Changing of Strut Mount on BMW E82 2006 won't be an issue if you follow this illustrated step-by-step guide
    Remove the wheel.
  10. Step 10
    BMW 1 SERIES 123 d Strut Mount replacement: online guides and video tutorials
    Clean the stabiliser link fasteners. Use a wire brush. Use WD-40 spray.
  11. Step 11
    Replacing Strut Mount on BMW E82 2008 120 d by yourself
    Unscrew the fastener connecting the stabilizer link to the shock strut. Use a combination spanner #18. Use a drive socket #15. Use a ratchet wrench.
  12. Step 12
    1 Coupe (E82) 125 i 2009 Strut Mount DIY replacement workshop manual
    Remove the stabilizer rod.
  13. Step 13
    How to change Strut Mount on BMW 1 Coupe (E82) 2010 - tips and tricks
    Disconnect the ABS sensor wiring.
  14. Step 14
    Step-by-step recommendations for DIY replacement BMW E82 2011 125 i Strut Mount
    Detach the ABS sensor connector.
  15. Step 15
    DIY replacement of Strut Mount on BMW 1 Coupe (E82) 135i 3.0 2012 is not an issue anymore with our step-by-step tutorial
    Spread the brake pads. Use a crowbar.
  16. Step 16
    How to change Strut Mount on BMW E82 2006 - free PDF and video manuals
    Clean the brake caliper bracket fasteners. Use a wire brush. Use WD-40 spray.
  17. Step 17
    How to replace BMW 1 Coupe (E82) 120 d 2007 Strut Mount - step-by-step manuals and video guides
    Unscrew the caliper bracket fastening. Use a drive socket #18. Use a tap wrench.
  18. Step 18
    BMW E82 123 d 2008 Strut Mount replacement: free workshop manuals
    Remove the brake caliper together with its bracket.
    Replacement: strut mount – BMW E82. AUTODOC recommends:
    Tie the caliper to the suspension or to the body with a wire without disconnecting from the brake hose to prevent depressurization of the brake system.Make sure that the brake caliper is not hanging on the brake hose.Don't press the brake pedal after the brake caliper has been removed. As a result, the piston can fall out from the brake cylinder, and brake fluid leakage and depressurization of the system may occur.
  19. Step 19
    Changing Strut Mount on BMW 1 Coupe (E82) 118d 2.0 2009 by yourself
    Clean the fastener connecting the tie rod end to the steering knuckle. Use a wire brush. Use WD-40 spray.
  20. Step 20
    How to remove BMW 1 SERIES 125 i 2010 Strut Mount - online easy-to-follow instructions
    Unscrew the end fastening nut to the steering knuckle. Use a drive socket #21. Use a ratchet wrench.
  21. Step 21
    How to replace Strut Mount on BMW 1 Coupe (E82) 2011: download PDF manuals and video instructions
    Disconnect the tie rod end from the steering knuckle.
  22. Step 22
    How hard is it to do yourself: Strut Mount replacement on BMW E82 120i 2.0 2012 - download illustrated guide
    Clean all joints of the arm. Use a wire brush. Use WD-40 spray.
  23. Step 23
    Need to know how to renew Strut Mount on BMW 1 SERIES 2013? This free workshop manual will help you to do it yourself
    Unscrew the rear fastener connecting the control arm to the subframe. Use a combination spanner #18. Use a drive socket #18. Use a ratchet wrench.
  24. Step 24
    Changing of Strut Mount on BMW E82 2006 won't be an issue if you follow this illustrated step-by-step guide
    Clean the fasteners connecting the shock strut to the steering knuckle. Use a wire brush. Use WD-40 spray.
  25. Step 25
    BMW 1 SERIES 123 d Strut Mount replacement: online guides and video tutorials
    Unscrew the lower fastener connecting the shock strut to the steering knuckle. Use a combination spanner #18. Use a drive socket #18. Use a ratchet wrench.
  26. Step 26
    Replacing Strut Mount on BMW E82 2008 120 d by yourself
    Unscrew the front arm fastener. Use a combination spanner #18. Use a drive socket #18. Use a ratchet wrench.
  27. Step 27
    1 Coupe (E82) 125 i 2009 Strut Mount DIY replacement workshop manual
    Remove the fastening bolts.
  28. Step 28
    How to change Strut Mount on BMW 1 Coupe (E82) 2010 - tips and tricks
    Remove the control arms. Use a crowbar.
  29. Step 29
    Step-by-step recommendations for DIY replacement BMW E82 2011 125 i Strut Mount
    Remove the fastening bolt.
  30. Step 30
    DIY replacement of Strut Mount on BMW 1 Coupe (E82) 135i 3.0 2012 is not an issue anymore with our step-by-step tutorial
    Prop up the steering knuckle. Use a hydraulic transmission jack.
  31. Step 31
    How to change Strut Mount on BMW E82 2006 - free PDF and video manuals
    Release the lower fastener connecting the shock strut to the steering knuckle. Use a special drive socket to remove the shock absorber. Use a ratchet wrench.
  32. Step 32
    How to replace BMW 1 Coupe (E82) 120 d 2007 Strut Mount - step-by-step manuals and video guides
    Lower the hydraulic transmission jack by 10-15 cm.
    AUTODOC recommends:
    Replacement: strut mount – BMW E82. Lower the transmission jack smoothly, without jerks, to avoid damaging components and mechanisms.
  33. Step 33
    BMW E82 123 d 2008 Strut Mount replacement: free workshop manuals
    Disconnect the steering knuckle from the shock absorber strut.
  34. Step 34
    Changing Strut Mount on BMW 1 Coupe (E82) 118d 2.0 2009 by yourself
    Unscrew the top fastening of the shock strut mount.
    Replacement: strut mount – BMW E82. Tip from AUTODOC:
    To avoid injuries, hold the shock strut when undoing the fastening bolts.
  35. Step 35
    How to remove BMW 1 SERIES 125 i 2010 Strut Mount - online easy-to-follow instructions
    Remove the suspension strut.
  36. Step 36
    How to replace Strut Mount on BMW 1 Coupe (E82) 2011: download PDF manuals and video instructions
    Set the shock absorber strut on the spring compressor tool.
    Replacement: strut mount – BMW E82. Tip from AUTODOC experts:
    Note that when using a spring compressor, spring coils need to be securely gripped, compressing the spring on the opposite sides.Ensure the correct position of the spring in the retainer.Make sure that the spring coils tightly entered the lock handles.
  37. Step 37
    How hard is it to do yourself: Strut Mount replacement on BMW E82 120i 2.0 2012 - download illustrated guide
    Compress the spring.
  38. Step 38
    Need to know how to renew Strut Mount on BMW 1 SERIES 2013? This free workshop manual will help you to do it yourself
    Remove the shock strut mount cap. Use a crowbar.
  39. Step 39
    Changing of Strut Mount on BMW E82 2006 won't be an issue if you follow this illustrated step-by-step guide
    Treat the shock strut rod. Use a wire brush. Use WD-40 spray.
  40. Step 40
    BMW 1 SERIES 123 d Strut Mount replacement: online guides and video tutorials
    Remove the strut piston rod nut. Use a drive socket #21. Use HEX No.H6. Use a ratchet wrench.
  41. Step 41
    Replacing Strut Mount on BMW E82 2008 120 d by yourself
    Remove the top strut mount.
    Replacement: strut mount – BMW E82. Professionals recommend:
    Examine the shock absorber dust cap and the bump stop. Replace them if necessary.
  42. Step 42
    1 Coupe (E82) 125 i 2009 Strut Mount DIY replacement workshop manual
    Install the upper strut mount and the strut mount bearing.
  43. Step 43
    How to change Strut Mount on BMW 1 Coupe (E82) 2010 - tips and tricks
    Tighten the shock strut piston rod nut. Use a drive socket #21. Use HEX No.H6. Use a torque wrench. Tighten it to 64 Nm torque.
    Replacement: strut mount – BMW E82. AUTODOC recommends:
    Check to make sure the spring is positioned correctly. Avoid its misalignment.
  44. Step 44
    Step-by-step recommendations for DIY replacement BMW E82 2011 125 i Strut Mount
    Treat the shock strut rod. Use copper grease.
  45. Step 45
    DIY replacement of Strut Mount on BMW 1 Coupe (E82) 135i 3.0 2012 is not an issue anymore with our step-by-step tutorial
    Install the shock strut mount cap.
  46. Step 46
    How to change Strut Mount on BMW E82 2006 - free PDF and video manuals
    Decompress the spring.
  47. Step 47
    How to replace BMW 1 Coupe (E82) 120 d 2007 Strut Mount - step-by-step manuals and video guides
    Remove the assembled shock strut.
  48. Step 48
    BMW E82 123 d 2008 Strut Mount replacement: free workshop manuals
    Treat the shock strut mounting seat on the steering knuckle. Use a wire brush. Use WD-40 spray.
  49. Step 49
    Changing Strut Mount on BMW 1 Coupe (E82) 118d 2.0 2009 by yourself
    Install the shock strut into the wheel arch.
  50. Step 50
    How to remove BMW 1 SERIES 125 i 2010 Strut Mount - online easy-to-follow instructions
    Screw the top fastening of the shock strut mount. Do not tighten it.
    AUTODOC recommends:
    Important! Hold the suspension strut while screwing in the fastening bolts. BMW E82
