How to carry out replacement: Control Arm 2.5 TDI quattro Audi A6 C5 Avant
Disclaimer
Change Audi A6 C5 Avant 1.9 TDI Control Arm yourself – manuals and video tutorials

How to change front lower arm on Audi A6 C5 Avant – replacement guide

downloads: 4
Views: 96
Download your free tutorial and fix AUDI A6 Avant (4B5, C5) 2.5 TDI quattro problems yourself Download for free 2.01 MB Control Arm for Audi A6 C5 Avant Shop now
Leave a comment Open in a new tab
Important!
This replacement procedure can be used for:
AUDI A6 Avant (4B5, C5) 2.4 quattro, AUDI A6 Avant (4B5, C5) 1.9 TDI, AUDI A6 Avant (4B5, C5) 1.8, AUDI A6 Avant (4B5, C5) 2.8 quattro, AUDI A6 Avant (4B5, C5) 1.8 T, AUDI A6 Avant (4B5, C5) 2.8, AUDI A6 Avant (4B5, C5) 1.8 T quattro, AUDI A6 Avant (4B5, C5) 2.5 TDI, AUDI A6 Avant (4B5, C5) 2.5 TDI quattro, AUDI A6 Avant (4B5, C5) 2.7 T, AUDI A6 Avant (4B5, C5) 2.7 T quattro, AUDI A6 Avant (4B5, C5) 2.4, AUDI A6 Avant (4B5, C5) 1.8 T quattro, AUDI A6 Avant (4B5, C5) 3.7 quattro, AUDI A6 Avant (4B5, C5) 3.7, AUDI A6 Avant (4B5, C5) 4.2 quattro, AUDI A6 Avant (4B5, C5) 1.8 T, AUDI A6 Avant (4B5, C5) S6 quattro, AUDI A6 Avant (4B5, C5) 2.5 TDI, AUDI A6 Avant (4B5, C5) 2.5 TDI quattro, AUDI A6 Avant (4B5, C5) 1.9 TDI, AUDI A6 Avant (4B5, C5) 1.8, AUDI A6 Avant (4B5, C5) 2.8, AUDI A6 Avant (4B5, C5) 2.8, AUDI A6 Avant (4B5, C5) 2.4, AUDI A6 Avant (4B5, C5) 2.0, AUDI A6 Avant (4B5, C5) 2.4, AUDI A6 Avant (4B5, C5) 2.4 quattro, AUDI A6 Avant (4B5, C5) 2.5 TDI, AUDI A6 Avant (4B5, C5) 2.7 T quattro, AUDI A6 Avant (4B5, C5) 3.0, AUDI A6 Avant (4B5, C5) 3.0 quattro, AUDI A6 Avant (4B5, C5) 1.9 TDI, AUDI A6 Avant (4B5, C5) RS6 quattro, AUDI A6 Avant (4B5, C5) 2.4, AUDI A6 Avant (4B5, C5) 2.4 quattro, AUDI A6 Avant (4B5, C5) 2.5 TDI, AUDI A6 Avant (4B5, C5) 2.4 quattro, AUDI A6 Avant (4B5, C5) RS6 plus quattro, AUDI A6 Avant (4B5, C5) 3.0, AUDI A6 Avant (4B5, C5) 3.0 quattro … View more

The steps may slightly vary depending on the car design.

How to change front suspension arm on AUDI A6 C5 Avant [TUTORIAL AUTODOC]

video
Published on: 24/05/2021
4K views
All the parts you need to replace – Control Arm for A6 Avant (4B5, C5) and other AUDI models
How to change Suspension arm on Audi A6 C5 Avant 2.5 TDI quattro – step-by-step instructions for straightforward car repair Suspension arm
How to change Link Set, wheel suspension on Audi A6 C5 Avant 2.5 TDI quattro – step-by-step instructions for straightforward car repair Link Set, wheel suspension
How to change Rod / Strut, wheel suspension on Audi A6 C5 Avant 2.5 TDI quattro – step-by-step instructions for straightforward car repair Rod / Strut, wheel suspension
How to change Suspension arm on AUDI A6 Avant (4B5, C5) 1.9 TDI – tips for proper car maintenance
Suspension arm for AUDI A6 Avant (4B5, C5) 1.9 TDI Diesel (110 hp)
Simple DIY car repair steps – Replacing Suspension arm on AUDI A6 Avant (4B5, C5) 1.8
Suspension arm for AUDI A6 Avant (4B5, C5) 1.8 Petrol (125 hp)
Easy tricks to help you to replace Suspension arm on AUDI A6 Avant (4B5, C5) 2.8 quattro
Suspension arm for AUDI A6 Avant (4B5, C5) 2.8 quattro Petrol (193 hp)
Suspension arm removal & installation, incredibly easy steps for AUDI A6 Avant (4B5, C5) 1.8 T
Suspension arm for AUDI A6 Avant (4B5, C5) 1.8 T Petrol (150 hp)
Changing Suspension arm on AUDI A6 Avant (4B5, C5) 2.8 – tips for first time repair
Suspension arm for AUDI A6 Avant (4B5, C5) 2.8 Petrol (193 hp)
Main steps for Suspension arm replacement on AUDI A6 Avant (4B5, C5) 1.8 T quattro
Suspension arm for AUDI A6 Avant (4B5, C5) 1.8 T quattro Petrol (150 hp)
How to change Suspension arm on AUDI A6 Avant (4B5, C5) 2.4 quattro – tips for proper car maintenance
Suspension arm for AUDI A6 Avant (4B5, C5) 2.4 quattro Petrol (165 hp)
Simple DIY car repair steps – Replacing Suspension arm on AUDI A6 Avant (4B5, C5) 2.5 TDI
Suspension arm for AUDI A6 Avant (4B5, C5) 2.5 TDI Diesel (150 hp)
Easy tricks to help you to replace Suspension arm on AUDI A6 Avant (4B5, C5) 2.5 TDI quattro
Suspension arm for AUDI A6 Avant (4B5, C5) 2.5 TDI quattro Diesel (150 hp)
Tools
Replacement: front lower arm – Audi A6 C5 Avant. Tools you might need:
Wire brush
WD-40 spray
Brake cleaner
Copper grease
Torque wrench
Combination spanner #18
Drive socket # 18
Wheel impact socket #17
Ball joint puller
Tap wrench
Crow bar
Hydraulic transmission jack
Wheel chock
Buy tools
Replacement: front lower arm – Audi A6 C5 Avant. AUTODOC experts recommend:
  • The replacement procedure is identical for the left and right lower control arms.
  • Please note: all work on the car – Audi A6 C5 Avant – should be done with the engine switched off.
Carry out replacement in the following order:
  1. Step 1
    Secure the wheels with chocks.
    Step 2
    How to change Control Arm on Audi A6 C5 Avant 1997 - free PDF and video manuals
    Loosen the wheel mounting bolts. Use wheel impact socket #17.
  2. Step 3
    How to replace AUDI A6 Avant (4B5, C5) 2.5 TDI quattro 1998 Control Arm - step-by-step manuals and video guides
    Raise the front of the car and secure on supports.
  3. Step 4
    Audi A6 C5 Avant 1.9 TDI 1999 Control Arm replacement: free workshop manuals
    Unscrew the wheel bolts.
    AUTODOC recommends:
    Warning! To avoid injury, hold the wheel while unscrewing the fastening bolts. Audi A6 C5 Avant
  4. Step 5
    Changing Control Arm on AUDI A6 Avant (4B5, C5) 2.5 TDI 2000 by yourself
    Remove the wheel.
  5. Step 6
    How to remove AUDI A6 1.8 T 2001 Control Arm - online easy-to-follow instructions
    Clean all joints of the arm. Use a wire brush. Use WD-40 spray.
    AUTODOC recommends:
    Replacement: front lower arm – Audi A6 C5 Avant. After applying the spray, wait a few minutes.Wear protective goggles.Wear a respirator.
  6. Step 7
    How to replace Control Arm on AUDI A6 Avant (4B5, C5) 2002: download PDF manuals and video instructions
    Unscrew the rear fastener connecting the control arm to the subframe. Use a combination spanner #18. Use a drive socket #18. Use a ratchet wrench.
  7. Step 8
    How hard is it to do yourself: Control Arm replacement on Audi A6 C5 Avant 1.8 T quattro 2003 - download illustrated guide
    Unscrew the ball joint fastening to the steering knuckle. Use a combination spanner #18.
  8. Step 9
    Need to know how to renew Control Arm on AUDI A6 2004? This free workshop manual will help you to do it yourself
    Support the arm. Use a hydraulic transmission jack.
  9. Step 10
    Changing of Control Arm on Audi A6 C5 Avant 2005 won't be an issue if you follow this illustrated step-by-step guide
    Disconnect the ball joint from the steering knuckle. Use a ball joint puller. Use a crowbar.
  10. Step 11
    AUDI A6 1.9 TDI Control Arm replacement: online guides and video tutorials
    Remove the retainers of the fasteners of the fuel filter tubes.
  11. Step 12
    Replacing Control Arm on Audi A6 C5 Avant 1998 2.5 TDI quattro by yourself
    Detach the tubes from the fuel filter.
  12. Step 13
    A6 Avant (4B5, C5) 1.8 T 1999 Control Arm DIY replacement workshop manual
    Remove the fastening bolt.
  13. Step 14
    How to change Control Arm on AUDI A6 Avant (4B5, C5) 2000 - tips and tricks
    Remove the arm.
  14. Step 15
    Step-by-step recommendations for DIY replacement Audi A6 C5 Avant 2001 1.8 T Control Arm
    Attach the tubes to the fuel filter.
  15. Step 16
    DIY replacement of Control Arm on AUDI A6 Avant (4B5, C5) 2.4 2002 is not an issue anymore with our step-by-step tutorial
    Install the retainers of the fasteners of the fuel filter tubes.
  16. Step 17
    How to change Control Arm on Audi A6 C5 Avant 1997 - free PDF and video manuals
    Clean the mounting seats and the thread of the suspension arm. Use a wire brush. Use WD-40 spray.
  17. Step 18
    How to replace AUDI A6 Avant (4B5, C5) 2.5 TDI quattro 1998 Control Arm - step-by-step manuals and video guides
    Install a new arm.
    AUTODOC recommends:
    Replacement: front lower arm – Audi A6 C5 Avant. Use only new bolts and nuts for installation.Do not damage the ball joint cover.
  18. Step 19
    Audi A6 C5 Avant 1.9 TDI 1999 Control Arm replacement: free workshop manuals
    Install the fastening bolt.
  19. Step 20
    Changing Control Arm on AUDI A6 Avant (4B5, C5) 2.5 TDI 2000 by yourself
    Screw the fastener connecting the control arm to the subframe. Use a combination spanner #18.
