How to carry out replacement: Brake Pads 1.6 TDI VW Golf Mk7
Disclaimer
Change VW Golf Mk7 2.0 TDI Brake Pads yourself – manuals and video tutorials

How to change front brake pads on VW Golf 7 – replacement guide

downloads: 93
Views: 2668
Download your free tutorial and fix VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.6 TDI problems yourself Download for free 1.62 MB Brake Pads for VW Golf Mk7 Shop now
Leave a comment Open in a new tab
When to replace the Brake Pads on your VW GOLF
Recommended replacement interval for the part category Brake pad set : 30000 km
Important!
This replacement procedure can be used for:
VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.4 TGI CNG, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.2 TSI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.4 TSI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.6 TDI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 TDI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.2 TSI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.4 TSI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.6 TDI 4motion, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 TDI 4motion, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.4 TSI MultiFuel, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.6 TDI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.6 TDI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 TDI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 TDI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 GTI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 GTI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 GTD, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.6 TDI 4motion, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 R 4motion, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) e-Golf, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.2 TSI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.4 TSI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.4 TSI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.4 GTE Hybrid, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 GTI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.4 TSI MultiFuel, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.6, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.0 TSI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 R 360S 4motion, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.0 TSI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.6 TDI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 R 4motion, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.0 TSI Flexfuel, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 R 4motion, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.0 TSI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 GTI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) e-Golf, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.5 TSI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 GTD, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.5 TSI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.5 TGI, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 GTI TCR, VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 GTI … View more

The steps may slightly vary depending on the car design.

How to change front brake pads on VW GOLF 7 [TUTORIAL AUTODOC]

video
Published on: 13/05/2022
25K views
All the parts you need to replace – Brake Pads for Golf VII Hatchback (5G1, BQ1, BE1, BE2) and other VW models
Alternative products
How to change Brake pad set on VW Golf Mk7 1.6 TDI – step-by-step instructions for straightforward car repair Brake pad set
Tools
Replacement: brake pads – VW Golf 7. List of the tools you'll need:
Wire brush
Nylon cleaning brush
Brake cleaner
Anti-squeal paste
Ceramic grease
Torque wrench
Combination spanner #17
Drive socket # 13
Wheel impact socket #17
Ratchet wrench
Brake caliper wind back tool
Crow bar
Wheel chock
Buy tools
Replacement: brake pads – VW Golf 7. AUTODOC experts recommend:
  • Perform the replacement of brake pads in complete set for each axis. This provides effective braking.
  • The replacement procedure is identical for all brake pads on the same axle.
  • Please note: all work on the car – VW Golf 7 – should be done with the engine switched off.
Carry out replacement in the following order:
  1. Step 1
    How to change Brake Pads on VW Golf Mk7 2012 - free PDF and video manuals
    Open the bonnet. Unscrew the brake fluid reservoir cap.
  2. Step 2
    Secure the wheels with chocks.
    Step 3
    How to replace VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.6 TDI 2013 Brake Pads - step-by-step manuals and video guides
    Loosen the wheel mounting bolts. Use wheel impact socket #17.
  3. Step 4
    VW Golf Mk7 2.0 TDI 2014 Brake Pads replacement: free workshop manuals
    Raise the car.
    Replacement: brake pads – VW Golf 7. Professionals recommend:
    If you are using a jack, make sure it rests on a flat surface without any unevenness.Be sure to additionally secure the car with jack stands.
  4. Step 5
    Changing Brake Pads on VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 GTI 2015 by yourself
    Unscrew the wheel bolts.
    AUTODOC recommends:
    Warning! To avoid injury, hold the wheel while unscrewing the fastening bolts. VW Golf 7
  5. Step 6
    How to remove VW GOLF 1.2 TSI 2016 Brake Pads - online easy-to-follow instructions
    Remove the wheel.
  6. Step 7
    How to replace Brake Pads on VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2017: download PDF manuals and video instructions
    Clean the brake caliper fasteners. Use a wire brush. Use a brake cleaner.
    AUTODOC recommends:
    Replacement: brake pads – VW Golf 7. After applying the spray, wait a few minutes.
  7. Step 8
    How hard is it to do yourself: Brake Pads replacement on VW Golf Mk7 2.0 R 4motion 2018 - download illustrated guide
    Unscrew the brake caliper fasteners. Use a combination spanner #17. Use a drive socket #13. Use a ratchet wrench.
  8. Step 9
    Need to know how to renew Brake Pads on VW GOLF 2019? This free workshop manual will help you to do it yourself
    Remove the fastening bolts.
  9. Step 10
    Changing of Brake Pads on VW Golf Mk7 2020 won't be an issue if you follow this illustrated step-by-step guide
    Spread the brake pads. Use a crowbar.
  10. Step 11
    VW GOLF 2.0 TDI Brake Pads replacement: online guides and video tutorials
    Remove the brake caliper.
    Replacement: brake pads – VW Golf 7. Tip from AUTODOC experts:
    Tie the caliper to the suspension or to the body with a wire without disconnecting from the brake hose to prevent depressurization of the brake system.Make sure that the brake caliper is not hanging on the brake hose.Don't press the brake pedal after the brake caliper has been removed. As a result, the piston can fall out from the brake cylinder, and brake fluid leakage and depressurization of the system may occur.
  11. Step 12
    Replacing Brake Pads on VW Golf Mk7 2012 1.6 TDI by yourself
    Remove the brake pads. Use a crowbar.
    Replacement: brake pads – VW Golf 7. Tip from AUTODOC:
    Measure the brake disc thickness. Upon reaching the wear limit the part must be replaced.
  12. Step 13
    Golf VII Hatchback (5G1, BQ1, BE1, BE2) 1.2 TSI 2013 Brake Pads DIY replacement workshop manual
    Treat the brake caliper piston. Use a nylon cleaning brush. Use a brake cleaner.
    AUTODOC recommends:
    After applying the spray, wait a few minutes.
  13. Step 14
    How to change Brake Pads on VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2014 - tips and tricks
    Press in the brake caliper piston. Use brake caliper wind back tool.
  14. Step 15
    Step-by-step recommendations for DIY replacement VW Golf Mk7 2015 1.2 TSI Brake Pads
    Clean the brake caliper bracket from dirt and dust. Use a wire brush. Use a brake cleaner.
    AUTODOC recommends:
    Replacement: brake pads – VW Golf 7. After applying the spray, wait a few minutes.Check the brake caliper bracket, brake caliper guide pins and boots. Clean them. Replace, if necessary.
  15. Step 16
    DIY replacement of Brake Pads on VW Golf VII Hatchback (5G1, BQ1, BE1, BE2) 2.0 GTD 2016 is not an issue anymore with our step-by-step tutorial
    Treat the brake pads in the area where their surface comes into contact with the brake caliper bracket. Use anti-squeal paste.
    Replacement: brake pads – VW Golf 7. AUTODOC experts recommend:
    Make sure the disc surface is clean before installing the pads.
