Important!

This replacement procedure can be used for:
BMW 1 Hatchback (E87) 116i, BMW 1 Hatchback (E87) 116i, BMW 1 Hatchback (E87) 116 i, BMW 1 Hatchback (E87) 118 i, BMW 1 Hatchback (E87) 118 i, BMW 1 Hatchback (E87) 118 i, BMW 1 Hatchback (E87) 120i, BMW 1 Hatchback (E87) 120i, BMW 1 Hatchback (E87) 120i, BMW 1 Hatchback (E87) 120i, BMW 1 Hatchback (E87) 130i, BMW 1 Hatchback (E87) 130i, BMW 1 Hatchback (E87) 116d, BMW 1 Hatchback (E87) 118d, BMW 1 Hatchback (E87) 118d, BMW 1 Hatchback (E87) 118d, BMW 1 Hatchback (E87) 120d, BMW 1 Hatchback (E87) 120d, BMW 1 Hatchback (E87) 123d, BMW 1 Hatchback (E87) 116 d, BMW 1 Hatchback (E87) 118 i … View more

The steps may slightly vary depending on the car design.

This video shows the replacement procedure of a similar car part on another vehicle

Alternative products

Anti-roll bar link

Replacement: anti roll bar links – BMW 1 (E87). AUTODOC experts recommend:

                      Wire brush

                      WD-40 spray

                      Brake cleaner

                      Copper grease

                      Combination spanner #17

                      Drive socket # 16

                      Wheel impact socket #17

                      Ratchet wrench

                      Torque wrench

                      Wheel chock

Buy tools

AUTODOC recommends:

Replace the stabiliser links on BMW 1 (E87) in pairs.
The replacement procedure is identical for both stabiliser links on the same axle.
Please note: all work on the car – BMW 1 (E87) – should be done with the engine switched off.

Carry out replacement in the following order:

Step 1

Secure the wheels with chocks.
Step 2

Loosen the wheel mounting bolts. Use wheel impact socket #17.
Step 3

Raise the front of the car and secure on supports.

Step 4

Unscrew the wheel bolts.

AUTODOC recommends:
Warning! To avoid injury, hold the wheel while unscrewing the fastening bolts. BMW 1 (E87)
Step 5

Remove the wheel.
Step 6

Clean the stabiliser link fasteners. Use a wire brush. Use WD-40 spray.

Step 7

Unscrew the fastener connecting the stabilizer link to the shock strut. Use a combination spanner #17. Use a drive socket #16. Use a ratchet wrench.
Step 8

Unscrew the fastener connecting the stabilizer link to the stabilizer bar. Use a combination spanner #17 (2 pieces).
Step 9

Remove the stabilizer rod.

Replacement: anti roll bar links – BMW 1 (E87). Tip from AUTODOC experts:
Examine stabiliser bushes. Replace them if needed.
Step 10

Clean the mounting seats of the stabiliser link. Use a wire brush. Use WD-40 spray.

Step 11

Install a new rod, tighten the fasteners.
Step 12

Tighten the fastener connecting the stabilizer link to the stabilizer bar. Use a combination spanner #17 (2 pieces). Use a torque wrench. Tighten it to 58 Nm torque.
Step 13

Tighten the fastener connecting the stabilizer link to the shock strut. Use a combination spanner #17. Use a drive socket #16. Use a torque wrench. Tighten it to 58 Nm torque.
Step 14

Treat all joints of the stabiliser link. Use copper grease.

Step 15

Treat the surface where the brake disc contacts the wheel rim. Use copper grease.
Step 16

Clean the brake disk surface. Use a brake cleaner.

AUTODOC recommends:
Replacement: anti roll bar links – BMW 1 (E87). After applying the spray, wait a few minutes.
Step 17

Install the wheel.

AUTODOC recommends:
Warning! To avoid injury, hold the wheel while screwing in the fastening bolts on the car. BMW 1 (E87)
Step 18

Screw in the wheel bolts. Use wheel impact socket #17.
Step 19

Lower the car and working in a cross order, tighten the wheel bolts. Use wheel impact socket #17. Use a torque wrench. Tighten it to 120 nm torque.
Step 20

Remove the jacks and chocks.
