When to replace the Pollen Filter on your MERCEDES-BENZ CLK
Recommended replacement interval for the part category Pollen filter : 2 year / 60000 km
Important!
This replacement procedure can be used for:
MERCEDES-BENZ CLK (C209) CLK 320 (209.365), MERCEDES-BENZ CLK (C209) CLK 500 (209.375), MERCEDES-BENZ CLK (C209) CLK 240 (209.361), MERCEDES-BENZ CLK (C209) CLK 200 Kompressor (209.342), MERCEDES-BENZ CLK (C209) CLK 200 CGI (209.343), MERCEDES-BENZ CLK (C209) CLK 270 CDI (209.316), MERCEDES-BENZ CLK (C209) CLK 55 AMG (209.376), MERCEDES-BENZ CLK (C209) CLK DTM AMG (209.376), MERCEDES-BENZ CLK (C209) CLK 350 (209.356), MERCEDES-BENZ CLK (C209) CLK 280 (209.354), MERCEDES-BENZ CLK (C209) CLK 220 CDI (209.308), MERCEDES-BENZ CLK (C209) CLK 320 CDI (209.320), MERCEDES-BENZ CLK (C209) CLK 63 AMG (209.377), MERCEDES-BENZ CLK (C209) CLK 500 (209.372), MERCEDES-BENZ CLK (C209) CLK 200 Kompressor (209.341), MERCEDES-BENZ CLK (C209) CLK 63 AMG (209.377), MERCEDES-BENZ CLK (C209) CLK 270 CDI (209.316), MERCEDES-BENZ CLK (C209) CLK 240 (209.361), MERCEDES-BENZ CLK (C209) CLK 220 CDI (209.308) View more

The steps may slightly vary depending on the car design.

This video shows the replacement procedure of a similar car part on another vehicle

Tools
Replacement: pollen filter – MERCEDES-BENZ CLK (C209). List of the tools you'll need:
Fender cover
Replacement: pollen filter – MERCEDES-BENZ CLK (C209). Professionals recommend:
  • Replace the cabin filter at least once every six months, in early spring and autumn seasons.
  • Follow the terms, recommendations and requirements of the part operation provided by the manufacturer.
  • If the air flow into the cabin has sharply reduced, replace the filter before a scheduled maintenance.
  • All work should be done with the engine stopped.
Carry out replacement in the following order:
  1. Step 1
    Open the bonnet.
    Step 2
    Use a fender protection cover to prevent damaging paintwork and plastic parts of the car.
    Step 3
    How to change Pollen Filter on CLK C209 2002 - free PDF and video manuals
    Release the cabin filter cover clips.
  2. Step 4
    How to replace MERCEDES-BENZ CLK (C209) CLK 270 CDI (209.316) 2003 Pollen Filter - step-by-step manuals and video guides
    Remove the cabin filter housing cover.
    AUTODOC recommends:
    Replacement: pollen filter – MERCEDES-BENZ CLK (C209). To avoid damaging the part when removing it, do not use excessive force.
  3. Step 5
    Switch on the ignition.
    Step 6
    Set the heater flap actuator to the upper position.
    Step 7
    Switch off the ignition.
    Step 8
    CLK C209 CLK 200 Kompressor (209.342) 2004 Pollen Filter replacement: free workshop manuals
    Clean the cabin filter housing and cover.
    Replacement: pollen filter – MERCEDES-BENZ CLK (C209). AUTODOC recommends:
    Remove any debris from the cabin filter housing carefully to prevent contamination of the ventilation duct.
  4. Step 9
    Changing Pollen Filter on MERCEDES-BENZ CLK (C209) CLK 220 CDI (209.308) 2005 by yourself
    Remove the filter element from the filter housing.
    Replacement: pollen filter – MERCEDES-BENZ CLK (C209). Tip from AUTODOC experts:
    Do not attempt to clean and reuse the filter - it will affect the quality of air cleaning inside the car.
  5. Step 10
    How to remove MERCEDES-BENZ CLK CLK 240 (209.361) 2006 Pollen Filter - online easy-to-follow instructions
    Insert a new filter element into the filter housing. Make sure that the filter edge fits tight to the housing.
    AUTODOC recommends:
    Check out the correct location of the filter element. Do not skew.Follow the air flow direction arrow on the filter.Attention! Use quality filters – MERCEDES-BENZ CLK (C209).
Was this manual helpful?
Please rate this manual on a scale from 1 to 5. If you have any questions, feel free to ask us.
Users voted – 0
