When to replace the Gearbox Oil and Transmission Oil on your OPEL ASTRA
Recommended replacement interval for the part category Manual Transmission Oil : 50000 km
Important!
This replacement procedure can be used for:
OPEL Astra G CC (T98) 1.2 16V (F08, F48), OPEL Astra G CC (T98) 1.6 (F08, F48), OPEL Astra G CC (T98) 1.6 16V (F08, F48), OPEL Astra G CC (T98) 1.8 16V (F08, F48), OPEL Astra G CC (T98) 2.0 16V (F08, F48), OPEL Astra G CC (T98) 1.7 TD (F08, F48), OPEL Astra G CC (T98) 2.0 DI (F08, F48), OPEL Astra G CC (T98) 2.2 DTI (F08, F48), OPEL Astra G CC (T98) 1.4 16V (F08, F48), OPEL Astra G CC (T98) 2.0 16V OPC (F08, F48), OPEL Astra G CC (T98) 2.0 DTI 16V (F08, F48), OPEL Astra G CC (T98) 1.7 DTI 16V (F08, F48), OPEL Astra G CC (T98) 1.6 (F08, F48), OPEL Astra G CC (T98) 1.8 16V (F08, F48), OPEL Astra G CC (T98) 2.2 16V (F08, F48), OPEL Astra G CC (T98) 2.0 OPC (F08, F48), OPEL Astra G CC (T98) 2.2 DTI (F08, F48), OPEL Astra G CC (T98) 1.7 CDTI (F08, F48), OPEL Astra G CC (T98) 1.6 (F08, F48), OPEL Astra G CC (T98) 2.0 OPC (F08, F48), OPEL Astra G CC (T98) 1.4 (F08, F48) View more

The steps may slightly vary depending on the car design.

How to change transmission oil on the OPEL ASTRA G CC (F48, F08) [TUTORIAL AUTODOC] problem-solving

video
All the parts you need to replace – Gearbox Oil and Transmission Oil for Astra G CC (T98) and other OPEL models
Tools
Replacement: manual gearbox oil – Opel Astra G F48. Tools you'll need:
Wire brush
All-purpose cleaning spray
Cleaner&thinner
Sealant
Drive socket # 11
Drive socket # 12
Drive socket # 16
Ratchet wrench
Torque wrench
Seal scraper
Funnel
Oil drain pan
Hydraulic transmission jack
Fender cover
Replacement: manual gearbox oil – Opel Astra G F48. AUTODOC experts recommend:
  • All work should be done with the engine stopped.
Replacement: manual gearbox oil – Opel Astra G F48. Take the following steps:
  1. Step 1
    How to change Gearbox Oil and Transmission Oil on Opel Astra g f48 1998 - free PDF and video manuals
    Open the hood.
  2. Step 2
    How to replace OPEL Astra G CC (T98) 1.6 16V (F08, F48) 1999 Gearbox Oil and Transmission Oil - step-by-step manuals and video guides
    Use a fender protection cover to prevent damaging paintwork and plastic parts of the car.
  3. Step 3
    Opel Astra g f48 1.6 (F08, F48) 2000 Gearbox Oil and Transmission Oil replacement: free workshop manuals
    Lift the car using a jack or place it over an inspection pit.
  4. Step 4
    Changing Gearbox Oil and Transmission Oil on OPEL Astra G CC (T98) 2.0 DTI 16V (F08, F48) 2001 by yourself
    Support the engine skid plate. Use a hydraulic transmission jack.
  5. Step 5
    How to remove OPEL ASTRA 1.7 DTI 16V (F08, F48) 2002 Gearbox Oil and Transmission Oil - online easy-to-follow instructions
    Undo the fasteners of the oil pan lower cover. Use a drive socket #12.
    Replacement: manual gearbox oil – Opel Astra G F48. AUTODOC recommends:
    To avoid injury, hold the engine skid plate cautiously tight when unscrewing the fasteners and when lowering the hydraulic transmission jack.
  6. Step 6
    How to replace Gearbox Oil and Transmission Oil on OPEL Astra G CC (T98) 2003: download PDF manuals and video instructions
    Remove the hydraulic transmission jack. Remove the oil pan cover.
    AUTODOC recommends:
    Replacement: manual gearbox oil – Opel Astra G F48. Lower the transmission jack smoothly, without jerks, to avoid damaging components and mechanisms.
  7. Step 7
    How hard is it to do yourself: Gearbox Oil and Transmission Oil replacement on Opel Astra g f48 2.0 DI (F08, F48) 2004 - download illustrated guide
    Clean the transmission fluid pan. Use a wire brush. Use all-purpose cleaning spray.
  8. Step 8
    Need to know how to renew Gearbox Oil and Transmission Oil on OPEL ASTRA 2005? This free workshop manual will help you to do it yourself
    Prepare a waste oil container with at least 2 l capacity.
  9. Step 9
    Changing of Gearbox Oil and Transmission Oil on Opel Astra g f48 2006 won't be an issue if you follow this illustrated step-by-step guide
    Unscrew the fasteners of the transmission fluid pan. Use a drive socket #11. Use a ratchet wrench.
  10. Step 10
    OPEL ASTRA 1.6 16V (F08, F48) Gearbox Oil and Transmission Oil replacement: online guides and video tutorials
    Remove the transmission fluid pan.
    Replacement: manual gearbox oil – Opel Astra G F48. Tip:
    When removing the transmission fluid pan, incline it so that the fluid only comes out from one side of it.
  11. Step 11
    Replacing Gearbox Oil and Transmission Oil on Opel Astra g f48 2008 1.6 16V (F08, F48) by yourself
    Drain the used oil.
    Replacement: manual gearbox oil – Opel Astra G F48. Professionals recommend:
    Wait until the fluid has completely run out of the pan.
  12. Step 12
    Astra G CC (T98) 1.7 DTI 16V (F08, F48) 2009 Gearbox Oil and Transmission Oil DIY replacement workshop manual
    Clean the mounting seat of the transmission fluid pan. Use all-purpose cleaning spray.
  13. Step 13
    How to change Gearbox Oil and Transmission Oil on OPEL Astra G CC (T98) 1998 - tips and tricks
    Remove the transmission fluid pan gasket. Use a seal scraper.
  14. Step 14
    Step-by-step recommendations for DIY replacement Opel Astra g f48 1999 1.7 DTI 16V (F08, F48) Gearbox Oil and Transmission Oil
    Clean the mounting seat of the transmission fluid pan gasket. Use a wire brush. Use cleaner&thinner.
  15. Step 15
    DIY replacement of Gearbox Oil and Transmission Oil on OPEL Astra G CC (T98) 1.4 16V (F08, F48) 2000 is not an issue anymore with our step-by-step tutorial
    Apply sealant to the mounting seat of the transmission fluid pan gasket. Install the new transmission fluid pan gasket.
  16. Step 16
    How to change Gearbox Oil and Transmission Oil on Opel Astra g f48 1998 - free PDF and video manuals
    Treat the mounting seat of the transmission fluid pan. Use cleaner&thinner.
    Replacement: manual gearbox oil – Opel Astra G F48. Tip from AUTODOC:
    Prevent fluid from getting on the mounting seat of the transmission fluid pan.
  17. Step 17
    How to replace OPEL Astra G CC (T98) 1.6 16V (F08, F48) 1999 Gearbox Oil and Transmission Oil - step-by-step manuals and video guides
    Install and fasten the transmission fluid pan.
  18. Step 18
    Opel Astra g f48 1.6 (F08, F48) 2000 Gearbox Oil and Transmission Oil replacement: free workshop manuals
    Tighten the fastening bolts of the transmission fluid pan in a criss-cross pattern. Use a drive socket #11. Use a torque wrench. Tighten it to 18 Nm torque.
