When to replace the Air Filter on your CITROËN C4
Recommended replacement interval for the part category Air filter : 4 year / 50000 km
Important!
This replacement procedure can be used for:
CITROËN C4 CACTUS 1.2 VTi / PureTech, CITROËN C4 CACTUS 1.2 VTi … View more

The steps may slightly vary depending on the car design.

This video shows the replacement procedure of a similar car part on another vehicle

All the parts you need to replace – Air Filter for C4 CACTUS and other CITROËN models
Alternative products
How to change Air filter on Citroen C4 Cactus 1.6 BlueHDi – step-by-step instructions for straightforward car repair Air filter
Tools
Replacement: air filter – CITROËN C4 CACTUS. Tools you might need:
Drive socket # 7
Drive socket # 10
Ratchet wrench
Phillips screwdriver
Microfibre towel
Fender cover
Buy tools
Replacement: air filter – CITROËN C4 CACTUS. AUTODOC experts recommend:
  • Follow the terms, recommendations and requirements of the part operation provided by the manufacturer.
  • All work should be done with the engine stopped.
Replacement: air filter – CITROËN C4 CACTUS. Recommended sequence of steps:
  1. Step 1
    Open the bonnet.
    Step 2
    Use a fender protection cover to prevent damaging paintwork and plastic parts of the car.
    Step 3
    How to change Air Filter on Citroen C4 Cactus 2014 - free PDF and video manuals
    Disconnect the crankcase ventilation hose from the air duct.
  2. Step 4
    How to replace CITROËN C4 CACTUS 1.6 BlueHDi 2015 Air Filter - step-by-step manuals and video guides
    Unscrew the clamp fastening the engine air filter housing to the throttle body. Use a drive socket #7.
  3. Step 5
    Citroen C4 Cactus 1.2 VTi 2016 Air Filter replacement: free workshop manuals
    Unscrew the filter housing fastening bolts. Use a drive socket #10. Use a ratchet wrench.
  4. Step 6
    Changing Air Filter on CITROËN C4 CACTUS 1.2 THP 2017 by yourself
    Disconnect the air intake pipe from the air filter housing.
  5. Step 7
    How to remove CITROËN C4 1.2 VTi / PureTech 2018 Air Filter - online easy-to-follow instructions
    Remove the air filter housing.
  6. Step 8
    How to replace Air Filter on CITROËN C4 CACTUS 2019: download PDF manuals and video instructions
    Undo the fastening screws of the air filter cover. Use a Phillips screwdriver.
  7. Step 9
    How hard is it to do yourself: Air Filter replacement on Citroen C4 Cactus 1.2 PureTech 2020 - download illustrated guide
    Take off the filter lid.
  8. Step 10
    Need to know how to renew Air Filter on CITROËN C4 2021? This free workshop manual will help you to do it yourself
    Remove the filter element from the filter housing.
  9. Step 11
    Changing of Air Filter on Citroen C4 Cactus 2022 won't be an issue if you follow this illustrated step-by-step guide
    Clean the air filter cover and housing.
    Replacement: air filter – CITROËN C4 CACTUS. Tip from AUTODOC experts:
    Before cleaning the air filter cover and housing, cover the air duct parts, mass airflow sensor (if available), throttle valve with a clean cloth.
  10. Step 12
    CITROËN C4 1.6 BlueHDi Air Filter replacement: online guides and video tutorials
    Insert a new filter element into the filter housing. Make sure that the filter edge fits tight to the housing.
    AUTODOC recommends:
    Replacement: air filter – CITROËN C4 CACTUS. Be sure to position the filtering element correctly. Avoid misalignment.Take care to only use quality filters.During installation, make sure to prevent dust and dirt from getting into the air filter housing.
