How to change air filter on Seat Ibiza 6L1 – replacement guide
downloads:
9
Views:
282
Recommended replacement interval for the part category Air filter : 4 year / 60000 km
Important!
This replacement procedure can be used for:
SEAT Ibiza III Hatchback (6L) 1.6, SEAT Ibiza III Hatchback (6L) 1.4 16V, SEAT Ibiza III Hatchback (6L) 1.4 16V … View more
The steps may slightly vary depending on the car design.
SEAT Ibiza III Hatchback (6L) 1.6, SEAT Ibiza III Hatchback (6L) 1.4 16V, SEAT Ibiza III Hatchback (6L) 1.4 16V … View more
The steps may slightly vary depending on the car design.
How to change air filter on SEAT IBIZA 3 6L [TUTORIAL AUTODOC]
All the parts you need to replace – Air Filter for Ibiza III Hatchback (6L) and other SEAT models
Air filter
Alternative products
Air filter
Phillips screwdriver
Microfibre towel
Fender cover
Replacement: air filter – Seat Ibiza 6L1. AUTODOC experts recommend:
- Follow the terms, recommendations and requirements of the part operation provided by the manufacturer.
- Please note: all work on the car – Seat Ibiza 6L1 – should be done with the engine switched off.
Carry out replacement in the following order:
- Step 1
Open the bonnet. - Step 2
Use a fender protection cover to prevent damaging paintwork and plastic parts of the car. - Step 3
On the right side, detach the PCV valve hose from the engine cover. - Step 4
Remove the engine cover The air filter housing is integrated into the engine cover.AUTODOC recommends:Replacement: air filter – Seat Ibiza 6L1. To avoid damaging the part when removing it, do not use excessive force. - Step 5
Cover the throttle body with a microfibre towel to prevent dust and dirt from getting into the system. - Step 6
Undo the fastening screws of the air filter cover. Use a Phillips screwdriver. - Step 7
Take off the filter lid. - Step 8
Remove the filter element from the filter housing. - Step 9
Clean the air filter cover and housing.Replacement: air filter – Seat Ibiza 6L1. Tip:Before cleaning the air filter cover and housing, cover the air duct parts, mass airflow sensor (if available), throttle valve with a clean cloth. - Step 10
Insert a new filter element into the filter housing. Make sure that the filter edge fits tight to the housing.AUTODOC recommends:Replacement: air filter – Seat Ibiza 6L1. Be sure to position the filtering element correctly. Avoid misalignment.Take care to only use quality filters.During installation, make sure to prevent dust and dirt from getting into the air filter housing.
