How to change front brake pads on Seat Ibiza 6L1 – replacement guide
downloads:
16
Views:
230
Recommended replacement interval for the part category Brake pad set : 30000 km
Important!
This replacement procedure can be used for:
SEAT Ibiza III Hatchback (6L) 1.2, SEAT Ibiza III Hatchback (6L) 1.4 16V, SEAT Ibiza III Hatchback (6L) 1.9 TDI, SEAT Ibiza III Hatchback (6L) 1.9 SDI, SEAT Ibiza III Hatchback (6L) 1.4 TDI, SEAT Ibiza III Hatchback (6L) 1.6, SEAT Ibiza III Hatchback (6L) 1.4 TDI, SEAT Ibiza III Hatchback (6L) 1.4 TDI, SEAT Ibiza III Hatchback (6L) 1.2 12V, SEAT Ibiza III Hatchback (6L) 1.6 16V, SEAT Ibiza III Hatchback (6L) 1.2 … View more
The steps may slightly vary depending on the car design.
SEAT Ibiza III Hatchback (6L) 1.2, SEAT Ibiza III Hatchback (6L) 1.4 16V, SEAT Ibiza III Hatchback (6L) 1.9 TDI, SEAT Ibiza III Hatchback (6L) 1.9 SDI, SEAT Ibiza III Hatchback (6L) 1.4 TDI, SEAT Ibiza III Hatchback (6L) 1.6, SEAT Ibiza III Hatchback (6L) 1.4 TDI, SEAT Ibiza III Hatchback (6L) 1.4 TDI, SEAT Ibiza III Hatchback (6L) 1.2 12V, SEAT Ibiza III Hatchback (6L) 1.6 16V, SEAT Ibiza III Hatchback (6L) 1.2 … View more
The steps may slightly vary depending on the car design.
How to change front brake pads SEAT IBIZA 3 6L [TUTORIAL AUTODOC]
All the parts you need to replace – Brake Pads for Ibiza III Hatchback (6L) and other SEAT models
Brake pad set
Alternative products
Brake pad set
Wire brush
Nylon cleaning brush
WD-40 spray
Brake cleaner
Anti-squeal paste
Copper grease
Torque wrench
HEX bit No.H7.
Wheel impact socket #17
Ratchet wrench
Brake caliper wind back tool
Crow bar
Wheel chock
Replacement: brake pads – Seat Ibiza 6L1. AUTODOC experts recommend:
- Perform the replacement of brake pads in complete set for each axis. This provides effective braking.
- The replacement procedure is identical for all brake pads on the same axle.
- All work should be done with the engine stopped.
Replacement: brake pads – Seat Ibiza 6L1. Recommended sequence of steps:
- Step 1
Open the bonnet. Unscrew the brake fluid reservoir cap. - Step 2
Secure the wheels with chocks. - Step 3
Loosen the wheel mounting bolts. Use wheel impact socket #17. - Step 4
Raise the front of the car and secure on supports. - Step 5
Unscrew the wheel bolts.Replacement: brake pads – Seat Ibiza 6L1. Tip:To avoid injury, hold up the wheel when unscrewing the bolts. - Step 6
Remove the wheel. - Step 7
Remove the dust boot caps of the brake caliper guide pins. Use a crowbar. - Step 8
Unscrew the brake caliper fastening. Use HEX No.H7. Use a ratchet wrench. - Step 9
Spread the brake pads. Use a crowbar. - Step 10
Remove the brake caliper.Replacement: brake pads – Seat Ibiza 6L1. AUTODOC experts recommend:Tie the caliper to the suspension or to the body with a wire without disconnecting from the brake hose to prevent depressurization of the brake system.Make sure that the brake caliper is not hanging on the brake hose.Don't press the brake pedal after the brake caliper has been removed. As a result, the piston can fall out from the brake cylinder, and brake fluid leakage and depressurization of the system may occur. Check the brake caliper bracket, brake caliper guide pins and boots. Clean them. Replace, if necessary. - Step 11
Remove the brake pads. Use a crowbar.AUTODOC recommends:Measure the brake disc thickness. Upon reaching the wear limit the part must be replaced. - Step 12
Clean the brake caliper bracket from dirt and dust. Use a wire brush. Use a brake cleaner.AUTODOC recommends:Replacement: brake pads – Seat Ibiza 6L1. After applying the spray, wait a few minutes. - Step 13
Treat the brake caliper piston. Use a nylon cleaning brush. Use a brake cleaner.AUTODOC recommends:After applying the spray, wait a few minutes. - Step 14
Press in the brake caliper piston. Use brake caliper wind back tool. - Step 15
Treat the brake pads in the area where their surface comes into contact with the brake caliper bracket. Use anti-squeal paste.Replacement: brake pads – Seat Ibiza 6L1. Professionals recommend:Make sure the disc surface is clean before installing the pads.
