Change BMW E91 318d 2.0 Control Arm yourself – manuals and video tutorials

How to change rear upper arm on BMW 3 Touring (E91) – replacement guide

downloads: 2
Views: 22
Download your free tutorial and fix BMW 3 Touring (E91) 320d problems yourself Download for free 1.25 MB Control Arm for BMW E91 Shop now
Leave a comment Open in a new tab
Important!
This replacement procedure can be used for:
BMW 3 Touring (E91) 325 i, BMW 3 Touring (E91) 318 d, BMW 3 Touring (E91) 318 i, BMW 3 Touring (E91) 316 d, BMW 3 Touring (E91) 320 i, BMW 3 Touring (E91) 325i, BMW 3 Touring (E91) 330 i, BMW 3 Touring (E91) 320d, BMW 3 Touring (E91) 330 d, BMW 3 Touring (E91) 325xi, BMW 3 Touring (E91) 330 xi, BMW 3 Touring (E91) 330 xd, BMW 3 Touring (E91) 318 d, BMW 3 Touring (E91) 318 i, BMW 3 Touring (E91) 335i, BMW 3 Touring (E91) 335 d, BMW 3 Touring (E91) 320 d, BMW 3 Touring (E91) 325 d, BMW 3 Touring (E91) 318 i, BMW 3 Touring (E91) 318 d, BMW 3 Touring (E91) 320i, BMW 3 Touring (E91) 335xi, BMW 3 Touring (E91) 330 i, BMW 3 Touring (E91) 330 xi, BMW 3 Touring (E91) 325 i, BMW 3 Touring (E91) 325xi, BMW 3 Touring (E91) 320d, BMW 3 Touring (E91) 323 i, BMW 3 Touring (E91) 330 d, BMW 3 Touring (E91) 330 d xDrive, BMW 3 Touring (E91) 316i, BMW 3 Touring (E91) 325i xDrive, BMW 3 Touring (E91) 330 i xDrive, BMW 3 Touring (E91) 335i xDrive, BMW 3 Touring (E91) 320d xDrive, BMW 3 Touring (E91) 320 d, BMW 3 Touring (E91) 320d xDrive, BMW 3 Touring (E91) 325 d, BMW 3 Touring (E91) 320 d xDrive, BMW 3 Touring (E91) 320 i, BMW 3 Touring (E91) 323 i, BMW 3 Touring (E91) 335i, BMW 3 Touring (E91) 335i xDrive, BMW 3 Touring (E91) 320 d, BMW 3 Touring (E91) 320 d, BMW 3 Touring (E91) 320 d xDrive, BMW 3 Touring (E91) 320 d xDrive, BMW 3 Touring (E91) 320 i, BMW 3 Touring (E91) 335xi, BMW 3 Touring (E91) 325 i, BMW 3 Touring (E91) 330d, BMW 3 Touring (E91) 325xi, BMW 3 Touring (E91) 325i xDrive, BMW 3 Touring (E91) 330i … View more

The steps may slightly vary depending on the car design.

This video shows the replacement procedure of a similar car part on another vehicle

All the parts you need to replace – Control Arm for 3 Touring (E91) and other BMW models
Alternative products
How to change Suspension arm on BMW E91 320d – step-by-step instructions for straightforward car repair Suspension arm
SKCA-0050469 STARK Suspension arm
19,86 GBP
Shop
273C0471 RIDEX Suspension arm
19,86 GBP
Shop
21071 SIDEM Rod / Strut, wheel suspension
21,17 GBP
Shop
BM-TC-3741 MOOG Suspension arm
21,68 GBP
Shop
V20-9511 VAICO Suspension arm
25,65 GBP
Shop
TC1945 DELPHI Rod / Strut, wheel suspension
25,80 GBP
Shop
QSJ3400S QUINTON HAZELL Suspension arm
26,33 GBP
Shop
210966 A.B.S. Suspension arm
27,04 GBP
Shop
51650 MAPCO Suspension arm
28,62 GBP
Shop
27193 FEBI BILSTEIN Suspension arm
34,56 GBP
Shop
Tools
Replacement: rear upper arm – BMW 3 Touring (E91). Tools you might need:
Wire brush
WD-40 spray
Brake cleaner
Copper grease
Combination spanner #18
Drive socket # 18
Wheel impact socket #17
Ratchet wrench
Torque wrench
Tap wrench
Flat Screwdriver
Hydraulic transmission jack
Wheel chock
Buy tools
Replacement: rear upper arm – BMW 3 Touring (E91). AUTODOC experts recommend:
  • The replacement procedure is identical for the right and left upper control arms.
  • Please note: all work on the car – BMW 3 Touring (E91) – should be done with the engine switched off.
Carry out replacement in the following order:
  1. Step 1
    How to change Control Arm on BMW E91 2004 - free PDF and video manuals
    Secure the wheels with chocks.
  2. Step 2
    How to replace BMW 3 Touring (E91) 320d 2005 Control Arm - step-by-step manuals and video guides
    Loosen the wheel mounting bolts. Use wheel impact socket #17.
  3. Step 3
    Raise the rear of the car and secure on supports.
    Step 4
    BMW E91 318d 2.0 2006 Control Arm replacement: free workshop manuals
    Unscrew the wheel bolts.
    AUTODOC recommends:
    Important! Hold the wheel while unscrewing the fastening bolts. BMW 3 Touring (E91)
  4. Step 5
    Changing Control Arm on BMW 3 Touring (E91) 325d 3.0 2007 by yourself
    Remove the wheel.
  5. Step 6
    Clean all joints of the arm. Use a wire brush. Use WD-40 spray.
    Step 7
    How to remove BMW 3 SERIES 330xd 3.0 2008 Control Arm - online easy-to-follow instructions
    Unscrew the fastener connecting the control arm to the rear knuckle. Use a drive socket #18. Use a tap wrench. Use a ratchet wrench.
  6. Step 8
    Remove the fastening bolt.
    Step 9
    How to replace Control Arm on BMW 3 Touring (E91) 2009: download PDF manuals and video instructions
    Detach the suspension arm from the rear knuckle.
  7. Step 10
    Disconnect the ABS sensor wiring. Use a flat screwdriver.
    Step 11
    How hard is it to do yourself: Control Arm replacement on BMW E91 320i 2.0 2010 - download illustrated guide
    Unscrew the arm fastening to the beam. Use a combination spanner #18 (2 pieces).
  8. Step 12
    Remove the rear fastener of the control arm.
    Step 13
    Need to know how to renew Control Arm on BMW 3 SERIES 2011? This free workshop manual will help you to do it yourself
    Remove the rear upper arm.
  9. Step 14
    Changing of Control Arm on BMW E91 2012 won't be an issue if you follow this illustrated step-by-step guide
    Clean the mounting seats and the thread of the suspension arm. Use a wire brush. Use WD-40 spray.
  10. Step 15
    BMW 3 SERIES 318d 2.0 Control Arm replacement: online guides and video tutorials
    Mount the rear upper arm.
    Replacement: rear upper arm – BMW 3 Touring (E91). AUTODOC experts recommend:
    During the installation process, use only new bolts and nuts.
  11. Step 16
    Install the rear fastener of the control arm.
    Step 17
    Replacing Control Arm on BMW E91 2005 320d by yourself
    Tighten the arm fastening to the beam. Use a combination spanner #18 (2 pieces). Use a torque wrench. Tighten it to 100 Nm torque.
    AUTODOC recommends:
    Important! Be sure to use new fasteners.
