Change Hyundai Santa Fe cm 2.2 CRDi GLS 4x4 Shock Absorber yourself – manuals and video tutorials

How to change rear shock absorbers on Hyundai Santa Fe CM – replacement guide

downloads: 4
Views: 339
Download your free tutorial and fix HYUNDAI SANTA FÉ II (CM) 2.2 CRDi 4x4 problems yourself Download for free 1.63 MB Shock Absorber for Hyundai Santa Fe cm Shop now
Leave a comment Open in a new tab
Important!
This replacement procedure can be used for:
HYUNDAI SANTA FÉ II (CM) 2.2 CRDi, HYUNDAI SANTA FÉ II (CM) 2.2 CRDi 4x4, HYUNDAI SANTA FÉ II (CM) 2.2 CRDi GLS, HYUNDAI SANTA FÉ II (CM) 2.2 CRDi GLS 4x4, HYUNDAI SANTA FÉ II (CM) 2.2 CRDi 4x4, HYUNDAI SANTA FÉ II (CM) 3.5 4x4, HYUNDAI SANTA FÉ II (CM) 2.0 CRDi, HYUNDAI SANTA FÉ II (CM) 2.4, HYUNDAI SANTA FÉ II (CM) 2.0 CRDi 4x4, HYUNDAI SANTA FÉ II (CM) 2.7 4x4, HYUNDAI SANTA FÉ II (CM) 2.7, HYUNDAI SANTA FÉ II (CM) 2.7 V6 GLS, HYUNDAI SANTA FÉ II (CM) 2.7 V6 GLS 4x4, HYUNDAI SANTA FÉ II (CM) 2.2 CRDi, HYUNDAI SANTA FÉ II (CM) 2.2 CRDi 4x4, HYUNDAI SANTA FÉ II (CM) 2.4 4x4, HYUNDAI SANTA FÉ II (CM) 2.7 4x4, HYUNDAI SANTA FÉ II (CM) 2.0 CRDi 4x4 … View more

The steps may slightly vary depending on the car design.

How to change rear shock absorbers on HYUNDAI SANTA FÉ CM TUTORIAL | AUTODOC

video
Published on: 18/02/2017
71K views
All the parts you need to replace – Shock Absorber for SANTA FÉ II (CM) and other HYUNDAI models
Alternative products
How to change Shock absorber on Hyundai Santa Fe cm 2.2 CRDi 4x4 – step-by-step instructions for straightforward car repair Shock absorber
Tools
Replacement: shock absorbers – Hyundai Santa Fe CM. List of the tools you'll need:
Wire brush
WD-40 spray
Brake cleaner
Copper grease
Torque wrench
Drive socket # 10
Drive socket # 19
Drive socket # 24
Wheel impact socket #21
Ratchet wrench
Hydraulic transmission jack
Crow bar
Wheel chock
Buy tools
Replacement: shock absorbers – Hyundai Santa Fe CM. Tip from AUTODOC experts:
  • Both shock absorbers of the rear suspension should be replaced simultaneously.
  • The replacement procedure is identical for the left and right shock absorbers of the rear suspension.
  • Please note: all work on the car – Hyundai Santa Fe CM – should be done with the engine switched off.
Carry out replacement in the following order:
  1. Step 1
    How to change Shock Absorber on Hyundai Santa Fe cm 2005 - free PDF and video manuals
    Secure the wheels with chocks.
  2. Step 2
    How to replace HYUNDAI SANTA FÉ II (CM) 2.2 CRDi 4x4 2006 Shock Absorber - step-by-step manuals and video guides
    Loosen the wheel mounting bolts. Use wheel impact socket #21.
  3. Step 3
    Hyundai Santa Fe cm 2.2 CRDi GLS 4x4 2007 Shock Absorber replacement: free workshop manuals
    Raise the rear of the car and secure on supports.
  4. Step 4
    Changing Shock Absorber on HYUNDAI SANTA FÉ II (CM) 2.7 V6 GLS 4x4 2008 by yourself
    Unscrew the wheel bolts.
    AUTODOC recommends:
    Warning! To avoid injury, hold the wheel while unscrewing the fastening bolts. Hyundai Santa Fe CM
  5. Step 5
    How to remove HYUNDAI SANTA FE 2.2 CRDi GLS 2009 Shock Absorber - online easy-to-follow instructions
    Remove the wheel.
  6. Step 6
    How to replace Shock Absorber on HYUNDAI SANTA FÉ II (CM) 2010: download PDF manuals and video instructions
    Support the rear knuckle. Use a hydraulic transmission jack.
  7. Step 7
    How hard is it to do yourself: Shock Absorber replacement on Hyundai Santa Fe cm 2.4 4x4 2011 - download illustrated guide
    Unscrew the fasteners of the control arm cover. Use a drive socket #10. Use a ratchet wrench.
  8. Step 8
    Remove the control arm cover.
    Step 9
    Clean the shock absorber fasteners. Use a wire brush. Use WD-40 spray.
    Step 10
    Need to know how to renew Shock Absorber on HYUNDAI SANTA FE 2012? This free workshop manual will help you to do it yourself
    Unscrew the lower fastener of the shock absorber. Use a drive socket #19. Use a ratchet wrench.
  9. Step 11
    Changing of Shock Absorber on Hyundai Santa Fe cm 2005 won't be an issue if you follow this illustrated step-by-step guide
    Unscrew the upper fastener of the shock absorber. Use a drive socket #24. Use a ratchet wrench.
  10. Step 12
    Remove the fastening bolt.
    Step 13
    HYUNDAI SANTA FE 2.2 CRDi GLS 4x4 Shock Absorber replacement: online guides and video tutorials
    Remove the shock absorber. Use a crowbar.
  11. Step 14
    Clean the shock absorber mounting seats. Use a wire brush. Use WD-40 spray.
    Replacement: shock absorbers – Hyundai Santa Fe CM. Professionals recommend:
    Before installing a new shock absorber you should pump it manually 3-5 times.
    Step 15
    Replacing Shock Absorber on Hyundai Santa Fe cm 2007 2.2 CRDi 4x4 by yourself
    Place the shock absorber in the wheel arch and fasten it.
    AUTODOC recommends:
    Hyundai Santa Fe CM – To avoid injury, hold the shock absorber while screwing in the fastening bolts.
