Recommended replacement interval for the part category Brake pad set : 30000 km

Important!

This replacement procedure can be used for:
ALFA ROMEO 147 (937) 2.0 16V T.SPARK (937.AXA1, 937.AXC1, 937.BXC1), ALFA ROMEO 147 (937) 1.6 16V T.SPARK ECO (937.AXA1A, 937.BXA1A), ALFA ROMEO 147 (937) 1.9 JTD (937.AXD1A, 937.BXD1A, 937.AXV1A, 937.BXB1A,..., ALFA ROMEO 147 (937) 3.2 GTA (937.AXL1), ALFA ROMEO 147 (937) 1.9 JTD 16V (937.AXG1B, 937.BXG1B), ALFA ROMEO 147 (937) 1.9 JTD (937.AXF1A, 937.BXF1A), ALFA ROMEO 147 (937) 1.9 JTDM 8V (937.AXD1A, 937.AXU1A, 937.BXU1A), ALFA ROMEO 147 (937) 1.9 JTDM 16V (937.AXN1B, 937.BXN1B), ALFA ROMEO 147 (937) 1.9 JTD 16V (937.AXG1B, 937.BXG1B), ALFA ROMEO 147 (937) 1.9 JTD 16V (937.AXM1B, 937.AXS1B), ALFA ROMEO 147 (937) 1.9 JTDM (937.AXD1A, 937.AXV1A, 937.BXB1A), ALFA ROMEO 147 (937) 1.9 JTDM 16V (937.AXN1B, 937.AXZ1B), ALFA ROMEO 147 (937) 3.2 GTA (937.AXL1B), ALFA ROMEO 147 (937) 1.9 JTD (937AXD1A, 937BXD1A), ALFA ROMEO 147 (937) 1.6 LPG (937BXB1A), ALFA ROMEO 147 (937) 1.6 LPG (937AXA1A) … View more

The steps may slightly vary depending on the car design.

How to change rear brake pads on ALFA ROMEO 147 (937) [TUTORIAL AUTODOC]

All the parts you need to replace – Brake Pads for 147 (937) and other ALFA ROMEO models

Alternative products

Brake pad set

402B0091 RIDEX Brake pad set

14,52 GBP

Shop

SKBP-0010091 STARK Brake pad set

14,62 GBP

Shop

6716 MAPCO Brake pad set

17,46 GBP

Shop

37184 A.B.S. Brake pad set

18,45 GBP

Shop

LP1685 DELPHI Brake pad set

19,94 GBP

Shop

573014J JURID Brake pad set

20,68 GBP

Shop

P 23 065 BREMBO Brake pad set

21,15 GBP

Shop

FDB1349 FERODO Brake pad set

21,35 GBP

Shop

0 986 424 553 BOSCH Brake pad set

22,61 GBP

Shop

13.0460-2867.2 ATE Brake pad set

28,84 GBP

Shop

Replacement: brake pads – Alfa Romeo 147 937. Tools you need:

                      Wire brush

                      WD-40 spray

                      Nylon cleaning brush

                      Brake cleaner

                      Anti-squeal paste

                      Copper grease

                      Torque wrench

                      Combination spanner #13

                      Drive socket # 13

                      Wheel impact socket #17

                      Brake caliper wind back tool

                      Crow bar

                      Wheel chock

Buy tools

Replacement: brake pads – Alfa Romeo 147 937. AUTODOC experts recommend:

Perform the replacement of brake pads in complete set for each axis. This provides effective braking.
The replacement procedure is identical for all brake pads on the same axle.
Please note: all work on the car – Alfa Romeo 147 937 – should be done with the engine switched off.

Carry out replacement in the following order:

Step 1

Open the hood. Unscrew the brake fluid reservoir cap.
Step 2

Secure the wheels with chocks.

Step 3

Loosen the wheel mounting bolts. Use wheel impact socket #17.
Step 4

Raise the rear of the car and secure on supports.
Step 5

Unscrew the wheel bolts.

AUTODOC recommends:
Warning! To avoid injury, hold the wheel while unscrewing the fastening bolts. Alfa Romeo 147 937
Step 6

Remove the wheel.
Step 7

Detach the brake hose from the shock strut. Use a crowbar.
Step 8

Clean the brake caliper fasteners. Use a wire brush. Use WD-40 spray.
Step 9

Unscrew the brake caliper fastening. Use a combination spanner #13.
Step 10

Spread the brake pads. Use a crowbar.
Step 11

Remove the brake caliper. Use a crowbar.

Replacement: brake pads – Alfa Romeo 147 937. Professionals recommend:
Tie the caliper to the suspension or to the body with a wire without disconnecting from the brake hose to prevent depressurization of the brake system.Make sure that the brake caliper is not hanging on the brake hose.Don't press the brake pedal after the brake caliper has been removed. As a result, the piston can fall out from the brake cylinder, and brake fluid leakage and depressurization of the system may occur.Check the brake caliper bracket, brake caliper guide pins and boots. Clean them. Replace, if necessary.
Step 12

Remove the brake pads. Use a crowbar.

Replacement: brake pads – Alfa Romeo 147 937. AUTODOC recommends:
Measure the brake disc thickness. Upon reaching the wear limit the part must be replaced.
Step 13

Clean the brake caliper bracket from dirt and dust. Use a wire brush. Use a brake cleaner.

AUTODOC recommends:
Replacement: brake pads – Alfa Romeo 147 937. After applying the spray, wait a few minutes.
Step 14

Treat the brake caliper piston. Use a nylon cleaning brush. Use a brake cleaner.

Replacement: brake pads – Alfa Romeo 147 937. AUTODOC experts recommend:
After applying the spray, wait a few minutes.
Step 15

Press in the brake caliper piston. Use brake caliper wind back tool.
Step 16

Treat the brake pads in the area where their surface comes into contact with the brake caliper bracket. Use anti-squeal paste.

Replacement: brake pads – Alfa Romeo 147 937. AUTODOC recommends:
Make sure the disc surface is clean before installing the pads.
Step 17

Install new brake pads.

Replacement: brake pads – Alfa Romeo 147 937. Tip:
Make sure the pads are installed with linings facing the disc.
Step 18

Install the brake caliper and fix it. Use a drive socket #13. Use a torque wrench. Tighten it to 35 Nm torque.
Step 19

Fasten the brake hose on the strut.

Step 20

Treat the surface where the brake disc contacts the wheel rim. Use copper grease.
Step 21

Clean the brake disk surface. Use a brake cleaner.

AUTODOC recommends:
Replacement: brake pads – Alfa Romeo 147 937. After applying the spray, wait a few minutes.
Step 22

Install the wheel.

AUTODOC recommends:
Warning! To avoid injury, hold the wheel while screwing in the fastening bolts on the car. Alfa Romeo 147 937
Step 23

Screw in the wheel bolts. Use wheel impact socket #17.
Step 24

Lower the car and working in a cross order, tighten the wheel bolts. Use wheel impact socket #17. Use a torque wrench. Tighten it to 108 Nm torque.
Step 25

Remove the jacks and chocks.

AUTODOC recommends:
Without starting the engine, press the brake pedal several times until you feel significant resistance.Check the brake fluid level in the expansion tank and refill if necessary.
Step 26

Tighten the brake fluid reservoir cap. Close the hood.

Replacement: brake pads – Alfa Romeo 147 937. Tip:
Slow down smoothly for first 150-200 km after the brake pads replacement. Avoid unneccessary and sharp braking to a stop.
