Important!

This replacement procedure can be used for:
SKODA Octavia II Combi (1Z5) 2.0 TDI 4x4, SKODA Octavia II Combi (1Z5) 1.6 TDI 4x4, SKODA Octavia II Combi (1Z5) 1.6 LPG, SKODA Octavia II Combi (1Z5) 2.0 TDI 16V 4x4, SKODA Octavia II Combi (1Z5) 1.4, SKODA Octavia II Combi (1Z5) 1.8 TSI 4x4, SKODA Octavia II Combi (1Z5) 1.8 TSI, SKODA Octavia II Combi (1Z5) 2.0 TDI, SKODA Octavia II Combi (1Z5) 1.6, SKODA Octavia II Combi (1Z5) 1.6 FSI, SKODA Octavia II Combi (1Z5) 1.9 TDI, SKODA Octavia II Combi (1Z5) 2.0 TDI 16V, SKODA Octavia II Combi (1Z5) 2.0 FSI, SKODA Octavia II Combi (1Z5) 2.0 FSI 4x4, SKODA Octavia II Combi (1Z5) 1.9 TDI 4x4, SKODA Octavia II Combi (1Z5) 2.0 TFSI, SKODA Octavia II Combi (1Z5) 2.0 TDI 4x4, SKODA Octavia II Combi (1Z5) 2.0 TDI, SKODA Octavia II Combi (1Z5) 1.4, SKODA Octavia II Combi (1Z5) 2.0 TDI RS, SKODA Octavia II Combi (1Z5) 2.0 TDI 16V, SKODA Octavia II Combi (1Z5) 1.6 MultiFuel, SKODA Octavia II Combi (1Z5) 1.6 TDI, SKODA Octavia II Combi (1Z5) 1.4 TSI, SKODA Octavia II Combi (1Z5) 1.8 TSI 4x4, SKODA Octavia II Combi (1Z5) 1.2 TSI … View more

The steps may slightly vary depending on the car design.

How to change front springs / front coil springs on OCTAVIA (1Z5) [TUTORIAL AUTODOC]

All the parts you need to replace – Springs for Octavia II Combi (1Z5) and other SKODA models

Coil spring

Supplementary Spring

Coil spring buffer

        Coil spring for SKODA Octavia II Combi (1Z5) 2.0 TDI 4x4 Diesel (110 hp)

        Coil spring for SKODA Octavia II Combi (1Z5) 1.6 TDI 4x4 Diesel (105 hp)

        Coil spring for SKODA Octavia II Combi (1Z5) 1.6 LPG Petrol/Petroleum Gas (LPG) (102 hp)

        Coil spring for SKODA Octavia II Combi (1Z5) 2.0 TDI 16V 4x4 Diesel (140 hp)

        Coil spring for SKODA Octavia II Combi (1Z5) 1.4 Petrol (75 hp)

        Coil spring for SKODA Octavia II Combi (1Z5) 1.8 TSI 4x4 Petrol (152 hp)

        Coil spring for SKODA Octavia II Combi (1Z5) 1.8 TSI Petrol (152 hp)

        Coil spring for SKODA Octavia II Combi (1Z5) 2.0 TDI Diesel (110 hp)

        Coil spring for SKODA Octavia II Combi (1Z5) 1.6 Petrol (102 hp)

Replacement: coil springs – Skoda Octavia 1Z5. List of the tools you'll need:

                        Wire brush

                        WD-40 spray

                        Brake cleaner

                        Copper grease

                        HEX bit no.H6.

                        HEX bit no.H7.

                        XZN socket bit # 14

                        Drive socket # 13

                        Drive socket # 16

                        Drive socket # 18

                        Drive socket # 21

                        Drive socket # 22

                        Drive socket # 24

                        Wheel impact socket #17

                        Ratchet wrench

                        Torque wrench

                        Tap wrench

                        Shock absorber socket

                        Crow bar

                        Hydraulic strut spring compressor

                        Hydraulic transmission jack

                        Fender cover

                        Wheel chock

Buy tools

Replacement: coil springs – Skoda Octavia 1Z5. AUTODOC experts recommend:

Both coil springs of the front suspension should be replaced simultaneously.
The replacement procedure is identical for the left and right coil springs of the front suspension.
Warning! Shut down the engine before starting any work – Skoda Octavia 1Z5.

Carry out replacement in the following order:

Step 1

Open the bonnet.
Step 2

Use a fender protection cover to prevent damaging paintwork and plastic parts of the car.
Step 3

Remove the cowl grille seal.
Step 4

Raise the wiper plastic cowl grille.
Step 5

Clean the fasteners of the shock strut upper mount. Use a wire brush. Use WD-40 spray.
Step 6

Loosen the upper fastener of the shock strut mount. Use a drive socket #13. Use a ratchet wrench.
Step 7

Secure the wheels with chocks.
Step 8

Loosen the wheel mounting bolts. Use wheel impact socket #17.
Step 9

Raise the front of the car and secure on supports.
Step 10

Unscrew the wheel bolts.

Replacement: coil springs – Skoda Octavia 1Z5. AUTODOC recommends:
To avoid injury, hold up the wheel when unscrewing the bolts.
Step 11

Remove the wheel.
Step 12

Clean the stabiliser link fasteners. Use a wire brush. Use WD-40 spray.
Step 13

Unscrew the fastener connecting the stabilizer link to the shock strut. Use a drive socket #18. Use a ratchet wrench.
Step 14

Remove the stabilizer rod.
Step 15

Disconnect the wiring and the brake hose from the bracket on the shock strut. Use a crowbar.
Step 16

Clean the fasteners connecting the shock strut to the steering knuckle. Use a wire brush. Use WD-40 spray.
Step 17

Loosen the fastener of the driveshaft. Use a drive socket #24. Use a tap wrench.
Step 18

Unscrew the lower fastener connecting the shock strut to the steering knuckle. Use XZN #14. Use a drive socket #18. Use a tap wrench. Use a ratchet wrench.
Step 19

Clean all joints of the arm. Use a wire brush. Use WD-40 spray.
Step 20

Unscrew the fastener connecting the ball joint to the suspension control arm. Use a drive socket #16. Use a ratchet wrench.
Step 21

Disconnect the spherical joint from the arm.
Step 22

Unscrew the fastener connecting the drive shaft to the wheel hub. Use a drive socket #24. Use a tap wrench.
Step 23

Remove the fastening bolt.
Step 24

Remove the drive shaft.
Step 25

Remove the fastening bolt.
Step 26

Release the lower fastener connecting the shock strut to the steering knuckle. Use a special drive socket to remove the shock absorber. Use a ratchet wrench.
Step 27

Prop up the steering knuckle. Use a hydraulic transmission jack.
Step 28

Disconnect the steering knuckle from the shock absorber strut.
Step 29

Unscrew the top fastening of the shock strut mount.

AUTODOC recommends:
Important! Hold the suspension strut while unscrewing the fastening bolts. Skoda Octavia 1Z5
Step 30

Remove the suspension strut.
Step 31

Set the shock absorber strut on the spring compressor tool.

Replacement: coil springs – Skoda Octavia 1Z5. Tip from AUTODOC experts:
Note that when using a spring compressor, spring coils need to be securely gripped, compressing the spring on the opposite sides.Ensure the correct position of the spring in the retainer.Make sure that the spring coils tightly entered the lock handles.
Step 32

Compress the spring.
Step 33

Treat the shock strut rod. Use a wire brush. Use WD-40 spray.
Step 34

Remove the strut piston rod nut. Use HEX No.H7. Use a drive socket #21. Use a ratchet wrench.
Step 35

Remove the shock absorber mount, boot and bump stop.

AUTODOC recommends:
Replacement: coil springs – Skoda Octavia 1Z5. Carefully inspect the mount, the boot, and the bump stop of the shock absorber. Replace if necessary.
Step 36

Release the coil spring.
Step 37

Remove the spring.
Step 38

Install the spring on the shock absorber.
Step 39

Compress the spring.
Step 40

Install the mount, the boot and the bump stop on the shock absorber.
Step 41

Tighten the shock strut piston rod nut. Use HEX No.H6. Use a drive socket #22. Use a torque wrench. Tighten it to 60 Nm torque.

Replacement: coil springs – Skoda Octavia 1Z5. Tip from AUTODOC:
Check to make sure the spring is positioned correctly. Avoid its misalignment.
Step 42

Treat the shock strut rod. Use copper grease.
Step 43

Decompress the spring.
Step 44

Remove the assembled shock strut.
Step 45

Treat the mounting seats of the shock strut. Use a wire brush. Use WD-40 spray.
Step 46

Install the shock strut into the wheel arch.
Step 47

Screw the top fastening of the shock strut mount. Do not tighten it.

AUTODOC recommends:
Skoda Octavia 1Z5 – To avoid injury, hold the suspension strut while screwing in the fastening bolts.
Step 48

Treat the shock strut mounting seat on the steering knuckle. Use a wire brush. Use WD-40 spray.
Step 49

Fix the shock absorber strut on the steering knuckle.
Step 50

Install the fastening bolt.
Step 51

Screw in the fastener that connects the shock strut to the steering knuckle. Use a drive socket #18. Use XZN #14. Use a ratchet wrench.
Step 52

Clean the splines of the drive shaft CV joint. Use a wire brush. Use WD-40 spray.
Step 53

Mount the drive shaft into the wheel hub.
Step 54

Remove the support from under the steering knuckle.

AUTODOC recommends:
Replacement: coil springs – Skoda Octavia 1Z5. Lower the transmission jack smoothly, without jerks, to avoid damaging components and mechanisms.
Step 55

Attach the ball joint to the control arm.
Step 56

Tighten the ball joint fastener. Use a drive socket #16. Use a torque wrench. Tighten it to 60 nm torque.
Step 57

Install and tighten the drive shaft bolt. Use a drive socket #24. Use a ratchet wrench.
Step 58

Tighten the lower fasteners connecting the shock strut to the steering knuckle. Use XZN #14. Use a drive socket #18. Use a torque wrench. Tighten it to 70 Nm torque.+90°

AUTODOC recommends:
Important! Be sure to use new fasteners.
Step 59

Connect the fastener of the ABS sensor cable to the shock absorber strut.
Step 60

Fasten the brake hose on the strut. Use a crowbar.

Step 61

Tighten the bolt connecting the drive shaft to the wheel hub. Use a drive socket #24. Use a torque wrench. Tighten it to 200 Nm torque.+90°

AUTODOC recommends:
Important! Be sure to use new fasteners.
Step 62

Ιnstall the transverse stabilizer link.
Step 63

Tighten the fastener connecting the stabilizer link to the shock strut. Use a drive socket #18. Use a torque wrench. Tighten it to 60 Nm torque.
Step 64

Treat the shock strut fasteners. Treat all joints of the arm. Use copper grease.
Step 65

Treat the surface where the brake disc contacts the wheel rim. Use copper grease.
Step 66

Clean the brake disk surface. Use a brake cleaner.

Replacement: coil springs – Skoda Octavia 1Z5. Tip:
After applying the spray, wait a few minutes.
Step 67

Install the wheel.

AUTODOC recommends:
Warning! To avoid injury, hold the wheel while screwing in the fastening bolts on the car. Skoda Octavia 1Z5
Step 68

Screw in the wheel bolts. Use wheel impact socket #17.
Step 69

Lower the car and working in a cross order, tighten the wheel bolts. Use wheel impact socket #17. Use a torque wrench. Tighten it to 120 Nm torque.
Step 70

Remove the jacks and chocks.
Step 71

Tighten the upper fastener of the shock absorber strut mount. Use a drive socket #13. Use a torque wrench. Tighten it to 15 Nm torque.+90°

AUTODOC recommends:
Important! Be sure to use new fasteners.
Step 72

Treat the fasteners of the shock strut mount. Use copper grease.
Step 73

Install and secure the cowl grille.
Step 74

Install the cowl grille seal.
Step 75

Remove the fender protection cover.
Step 76

Close the hood.
